BECKHOFF EP2xxx - Handbuch (Seite 149)

Inbetriebnahme/Konfiguration
Index 1A00 DIG TxPDO­Map Diag Inputs Ch.1
Index Name Bedeutung Data type Flags Default
1A00:0 DIG TxPDO­Map
Diag Inputs Ch.1 PDO Mapping
TxPDO 1 UINT8 RO 0x09 (9
dez
)
1A00:01 SubIndex 001 1. PDO Mapping
entry (object
0x6000 (DO
Inputs Ch.1),
entry 0x01 (Input
1)) UINT32 RO 0x6001:01, 1
1A00:02 SubIndex 002 2. PDO Mapping
entry (object
0x6000 (DO
Inputs Ch.1),
entry 0x02 (Input
2)) UINT32 RO 0x6001:02, 1
1A00:03 SubIndex 003 3. PDO Mapping
entry (object
0x6000 (DO
Inputs Ch.1),
entry 0x03 (Input
3)) UINT32 RO 0x6001:03, 1
1A00:04 SubIndex 004 4. PDO Mapping
entry (object
0x6000 (DO
Inputs Ch.1),
entry 0x04 (Input
4)) UINT32 RO 0x6001:04, 1
1A00:05 SubIndex 005 5. PDO Mapping
entry (object
0x6000 (DO
Inputs Ch.1),
entry 0x05 (Input
5)) UINT32 RO 0x6001:05, 1
1A00:06 SubIndex 006 6. PDO Mapping
entry (object
0x6000 (DO
Inputs Ch.1),
entry 0x06 (Input
6)) UINT32 RO 0x6001:06, 1
1A00:07 SubIndex 007 7. PDO Mapping
entry (object
0x6000 (DO
Inputs Ch.1),
entry 0x07 (Input
7)) UINT32 RO 0x6001:07, 1
1A00:08 SubIndex 008 8. PDO Mapping
entry (object
0x6000 (DO
Inputs Ch.1),
entry 0x08 (Input
8)) UINT32 RO 0x6001:08, 1
1A00:09 SubIndex 009 9. PDO Mapping
entry (5 bits
align) UINT32 RO 0x0000:00, 8
