6.5 Advanced Chipset Features
Phoenix – AwardBIOS CMOS Setup Utility
Advanced Chipset Features
DRAM Timing Selectable By SPD
Item Help
System BIOS Cacheable [Enabled]
Video BIOS Cacheable [Enabled]
** VGA Setting **
On-Chip Frame Buffer Size [ 8MB]
Boot Type [VBIOS Default]
LCD Panel Type [640x480 generic]
Panel Scaling [Auto]
BIA Control [VBIOS Default]
↑↓→←:Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
ü DRAM Timing Selectable
Optionen: keine
ü System BIOS Cacheable
Optionen: Enabled / Disabled
ü Video BIOS Cacheable
Optionen: Enabled / Disabled
ü On Chip Frame Buffer Size
Optionen: 1MB / 4MB / 8MB
ü Boot Type
Optionen: VBIOS Default / SDVO -> CRT / LVDS
ü LCD Panel Type
Optionen: 640x480 generic / 800x600 generic / 1024x768 generic / 640x480 NEC 8.4'' / 800x480
NEC 9'' / 1024x600 TMD 5.61'' / 1024x600 Samsung 4.8'' / 1024x768 Samsung 15'' /
1024x768 Sharp 7.2'' / 1280x800 Samsung 15.4
ü Panel Scaling
Optionen: Auto / Force / Off
ü BIA Control
Optionen: VBIOS Default / Level 1 / Level 2 / Level 3 / Level 4 / Level 5 / Level 6
