Kapitel: BIOS-Einstellungen
Integrated Peripherals
Seite 50
Beckhoff New Automation Technology CB4053
6.6 Integrated Peripherals
Phoenix – AwardBIOS CMOS Setup Utility
Integrated Peripherals
► OnChip IDE Device
[Press Enter]
Item Help
► Onboard Device
[Press Enter]
► PCI Express Root Port Func
[Press Enter]
Onboard FDC/LPT
[LPT]
Onboard Serial Port 1
[3F8/IRQ4]
Onboard Serial Port 2
[2F8/IRQ3]
UART Mode Select
[Normal]
x RxD , TxD Active
Hi,Lo
x IR Transmission Delay
Enabled
x UR2 Duplex Mode
Half
x Use IR Pins
IR-Rx2Tx2
Onboard Parallel Port
[378/IRQ7]
Parallel Port Mode
[SPP]
x EPP Mode Select
EPP1.7
► USB Device Setting
[Press Enter]
↑↓→←:Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
ü OnChip IDE Device
Untermenü: siehe "OnChip IDE Devices" (p. 52)
ü Onboard Device
Untermenü: siehe "Onboard Devices" (p. 53)
ü PCI Express Root Port Func
Untermenü: siehe "PCI Express Root Port Function" (p. 54)
ü Onboard FDC/LPT
Optionen: FDC / LPT / Disabled
ü Onboard Serial Port 1
Optionen: Disabled / 3F8/IRQ4 / 2F8/IRQ3 / 3E8/IRQ4 / 2E8/IRQ3 / Auto
ü Onboard Serial Port 2
Optionen: Disabled / 3F8/IRQ4 / 2F8/IRQ3 / 3E8/IRQ4 / 2E8/IRQ3 / Auto
ü UART Mode Select
Optionen: IrDA / ASKIR / Normal
ü RxD , TxD Active
Optionen: Hi,Hi / Hi,Lo / Lo,Hi / Lo,Lo
ü IR Transmission Delay
Optionen: Enabled / Disabled
ü UR2 Duplex Mode
Optionen: Full / Half
ü Use IR Pins
Optionen: RxD2,TxD2 / IR-Rx2Tx2
ü Onboard Parallel Port
Optionen: 378/IRQ7 / 278/IRQ5 / 3BC/IRQ7
