IMPAC Infrared sensor IN 2000
11
7.11 Address
The instruments are delivered with the standard address “00”. Only if several instru-
ments are connected via USB, different instrument addresses can be allocated for
better clearness.
Global addresses 98 and 99 (only via own communication program with interface
command, not possible with InfraWin, because InfraWin automatically detects a connected pyrometer): If
parameters may be changed simultaneously on all pyrometers, the global Address 98 can be used. This
allows you to program all pyrometers at the same time, regardless of the addresses that have already been
assigned. If the address of a pyrometer is unknown, it is possible to communicate with it using the global
Address 99 (connect only one pyrometer).
7.12
Operating hours
Shows the operation time since the pyrometer is in use.
7.13
Baud rate (Baud)
The transmission rate of the serial interface in Baud (Bd) is dependent on the length of
the cable. A standard cable length for 19200 Bd is 7 m. The baud rate is reduced by
50% if the transmission distance is doubled.
8 Software InfraWin
Note: For utilizing the software functions, the USB adapter is required (accessory)
Additionally to parameter adjustments the software InfraWin features the possibility of recording measure-
ment values inclusive displaying temperature measuring curves and subsequent analysis and storage.
This section gives an overview about the functions of the software. Additionally there is a software descrip-
tion in the program’s help menu.
The following descriptions refer to the program version 4.13. The latest version is available for free as
download from the homepage www.lumasenseinc.com.
8.1
Connecting the pyrometer to a PC
The program InfraWin can operate up to two devices. Every infrared thermometer has to be connected to a
single USB interface via an own USB adapter if 2 windows for settings or evaluation are to be displayed.
8.2
Installation
For installation select the setup program “setup.exe“ from the InfraWin-CD or from the downloaded and
unpacked zip file from the internet and follow the installation instructions.
8.3
Program start
After installation and the first program start a language must be chosen (German, English, French, Italian or
Spanish. The language also can be changed in the program). On the start page the screen shows the follow-
ing icons:
Settings:
00
. . .
97
Settings:
9600 Bd
19200 Bd
