Operation Instructions | HoE 1-00 | HDMI over Ethernet
10 2015-03-14 | © AXING AG | Swizzerland | Technical data are subject to change, errors and omissions excepted
5. Technical data
Input video signal 0.5-1.0 Vpp
Input DDC signal 5 Vpp (TTL)
Video format (DTV/HDTV) 480i/576i/480P/576P/720P/1080i/1080P
Video output HDMI, HDCP 1.3
Maximum transmission range
with 1080P 8-bit 120 m (CAT5E/6 /24AWG/Solid)
IR frequency 38 kHz
Transmission rang of the IR receiver
(HoE 1-01) 7 m
Operating voltage 5 VDC
Maximum power consumption 3 W
Operating temperature -5 - +35°C
Air humidity range 5 - 90% RH
Dimensions (W×H×D) 104 x 94 x 25 mm
Weight (transmitter/receiver) 220g
