KLING & FREITAG K&F SEQUENZA 5 W - Handbuch (Seite 71)

Benutzerhandbuch K&F SEQUENZA 5 inkl. Zubehör
KLING & FREITAG GMBH © 2015 Version 4.1 Seite 71 von 91
TO BE INSTALLED BY QUALIFIED
RIGGERS ONLY!
READ MANUAL AND SAFETY
INSTRUCTIONS BEFORE USE!
LOAD LIMIT:
IT'S MANDATORY TO CALCULATE
ANGLE SETTINGS AND LOAD
LIMIT WITH THE ARRAY SOFTWARE
'CON:SEQUENZA+' . ITS SAFETY
DIRECTIONS HAVE TO BE
FOLLOWED STRICTLY!
WT: 23,5 kg
SER.-NO.:
PWR:
IMP:
all pins parallel to out
-
1 - 2 -
1+
2+
+
IN
Prüfsiegelfeld am Flugrahmen
SEQUENZA 5
WT: 16,3 kg
SER.-NO.:
PWR: 350 W
IMP: 16 W
all pins parallel to out
-
1 - 2 -
1+
2+
+
IN
'CON:SEQUENZA+' . ITS
SAFETY DIRECTIONS HAVE TO
BE FOLLOWEDE STRICTLY!
ANGLE BETWEEN FRAME
AND 1st SEQUENZA 5
HOLE IN
CABINET
1st SEQUENZA 5
