Kapitel: BIOS-Einstellungen Advanced Chipset Features
Seite 44 Beckhoff New Automation Technology CB4050
5.5 Advanced Chipset Features
Phoenix – AwardBIOS CMOS Setup Utility
Advanced Chipset Features
DRAM Timing Selectable [By SPD]
Item Help
x CAS Latency Time 2.5
x Active to Precharge Delay 7
x DRAM RAS# to CAS# Delay 3
x DRAM RAS# Precharge 3
x DRAM Data Integrity Mode Non-ECC
MGM Core Frequency [Auto Max 266MHz]
System BIOS Cacheable [Enabled]
Video BIOS Cacheable [Enabled]
Memory Hole At 15M-16M [Disabled]
Delayed Transaction [Enabled]
Delay Prior to Thermal [16 Min]
AGP Aperture Size (MB) [64]
** On-Chip VGA Setting **
On-Chip VGA [Enabled]
On-Chip Frame Buffer Size [32MB]
Boot Display [LFP]
Panel Scaling [Off]
Panel Number [ 800*600 *18b-sp]
↑↓→←:Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
ü DRAM Timing Selectable
Optionen: By SPD / Manual
ü CAS Latency Time
Optionen: 2.5 / 2
ü Active to Precharge Delay
Optionen: 5 / 6 / 7
ü DRAM RAS# to CAS# Delay
Optionen: 2 / 3
ü DRAM RAS# Precharge
Optionen: 2 / 3
ü DRAM Data Integrity Mode
Optionen: keine
ü MGM Core Frequency
Optionen: Auto Max 266MHz /
400/266/133/200 MHz /
400/200/100/200 MHz /
400/200/100/133 MHz /
400/266/133/267 MHz /
400/333/166/250 MHz /
Auto Max 400/333 MHz
ü System BIOS Cacheable
Optionen: Enabled / Disabled
ü Video BIOS Cacheable
Optionen: Enabled / Disabled
ü Memory Hole At 15M-16M
Optionen: Enabled / Disabled
