Integrated Peripherals
Kapitel: BIOS-Einstellungen
Beckhoff New Automation Technology CB4057
Seite 51
5.6.2 SuperIO Devices
Phoenix – AwardBIOS CMOS Setup Utility
SuperIO Device
Onboard Serial Port 1
[3F8/IRQ4]
Item Help
Onboard Serial Port 2
[2F8/IRQ3]
Onboard Serial Port 3
[3E8/IRQ11]
Serial Port Mode
[RS232]
Onboard Serial Port 4
[2E8/IRQ10]
Serial Port Mode
[RS232]
Onboard Parallel Port
[378/IRQ7]
Parallel Port Mode
[SPP]
x ECP Mode Use DMA
3
↑↓→←:Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
ü Onboard Serial Port 1
Optionen: Disabled / 3F8/IRQ4 / 2F8/IRQ3 / 3E8/IRQ4 / 2E8/IRQ3
ü Onboard Serial Port 2
Optionen: Disabled / 3F8/IRQ4 / 2F8/IRQ3 / 3E8/IRQ4 / 2E8/IRQ3
ü Onboard Serial Port 3
Optionen: Disabled / 3F8/IRQ11 / 2F8/IRQ11 / 3E8/IRQ11 / 2E8/IRQ11
ü Serial Port Mode
Optionen: RS232 / RS485
ü Onboard Serial Port 4
Optionen: Disabled / 3F8/IRQ10 / 2F8/IRQ10 / 3E8/IRQ10 / 2E8/IRQ10
ü Serial Port Mode
Optionen: RS232 / RS485
ü Onboard Parallel Port
Optionen: Disabled / 378/IRQ7 / 278/IRQ5 / 3BC/IRQ7
ü Parallel Port Mode
Optionen: SPP / EPP1.9 + SPP / ECP / EPP1.9 + ECP / PRINTER / EPP1.7 + SPP / EPP1.7 +
ECP
ü ECP Mode Use DMA
Optionen: 1 / 3
