Fronius String Control 100/12 - Handbuch (Seite 87)

85
EN-US
Settings
General Settings for the Fronius String Control 100/12 are made in the "Fronius Solar.access" soft-
ware.
Initial Steps - Install Fronius Solar.access software on a PC
- Administration / Create PV System
- PV Systems / [System Name] / Settings / String Control
Possible Settings
for the Fronius
String Control
100/12 (1) Select the number (address) of the Fronius String Control 100/12 to be set
(2) Strings per Measuring Channel
(3) Limit values:
- max. energy deviation in %
- threshold value in Ah per string
Strings per Mea-
suring Channel Indication of the number of solar module strings for each measuring channel.
This results in automatic compensation of measuring channel deviations, which would only
be required if there were a different number of strings per channel.
(1)
(2)
(3)
