Configuration
G&D DVI-Extender-F · 12
Selecting the EDID mode of the KVM extender
The EDID information (Extended Display Identification Data) of a monitor inform the
graphics card of a connected computer about different technical device features. The
information are usually transmitted via Enhanced-DDC (Enhanced Display Data Chan-
nel) from KVM extender to the computer without alteration.
A special EDID mode can be activated if the computer connected to the KVM
extender is assembled with a Barco PVS graphics card. This mode considers the spe-
cial treatment of EDID data by the graphics card.
Use the default setting (Auto) when applying another graphics card.
How to select the EDID mode of the KVM extender:
1. Use the terminal emulation program to establish a connection to the KVM system.
2. Use the arrow keys to select the row EDID Mode .
3. Press Space (repeatedly) to select between the following settings:
4. Press S to save your settings.
IMPORTANT: It might be possible that Barco PVS graphics cards do not create an
image in the Auto mode!
Auto: automatic treatment of EDID data (default)
BARCO PVS: special mode for Barco PVS graphics cards
