Technical data
15 · G&D DVI-Extender-F
Technical data
GENERAL FEATURES
Graphics Colour depth: 24 bits
Max. resolution: 1920 × 1200 @ 60 Hz
Vertical frequency: 20 Hz to 120 Hz
Horizontal frequency: 25 kHz to 130 kHz
Pixel rate: max. 165 MHz
Main power supply Type: power pack
Connection: Mini-DIN 4 socket
Voltage: 12VDC
Operating environment Temperature: +5 to +45 °C
Air humidity: < 80%, non-condensing
TRANSMITTER (DVI-EXTENDER-F-CPU)
Interface
to computer
Video: 1 × DVI-D socket
Interface for
transmission
Video: 1 × LWL SC socket
Current consumption
 Operation
Main power supply: 180 mA @ 12VDC
Casing Material: anodised aluminium
Dimensionen (W × H × D): 104 mm × 105 mm × 26mm
RECEIVER (DVI-EXTENDER-F-CON)
Interface for
console
Monitor: 1 × DVI-D socket
Interface for
transmission
Video: 1 × LWL SC socket
Current consumption
 Operation
Main power supply: 140 mA @ 12VDC
Casing Material: anodised aluminium
Dimensions (W × H × D): 104 mm × 105 mm × 26mm
