6. DMX protocol
The P8 offers 3 different channel modes. In the menu area PERSONALITY -> DMX MODE you
can select your mode. The used mode will be displayed in the main menu.
Mode 1 (M1)
Mode 2 (M2)
Mode 3 (M3)
Channel 1
Pan
Pan
Pan
Channel 2
Pan fine
Pan fine
Pan fine
Channel 3
Tilt
Tilt
Tilt
Channel 4
Tilt fine
Tilt fine
Tilt fine
Channel 5
Control
Control
Control
Channel 6
Shutter
Shutter
Shutter
Channel 7
Dimmer
Dimmer
Dimmer
Channel 8
Iris
Iris
Iris
Channel 9
Focus
Focus
Focus
Channel 10
Gobo 1
Gobo 1
Gobo 1
Channel 11
Gobo 1 rotation
Gobo 1 rotation
Gobo 1 rotation
Channel 12
Gobo 2
Gobo 1 rotation fine
Gobo 2
Channel 13
Gobo 2 rotation
Gobo 2
Gobo 2 rotation
Channel 14
Prism
Gobo 2 rotation
Prism
Channel 15
Prism rotation
Gobo 2 rotation fine
Prism rotation
Channel 16
CTC 3200K
Prism
CTC 3200K
Channel 17
Fixed colors
Prism rotation
Fixed colors
Channel 18
Pan/Tilt speed
CTC 3200K
Blackout move
Channel 19
Effect speed
Fixed colors
Animation wheel
Channel 20
Blackout move
PAN/Tilt speed
Animation wheel rotation
Channel 21
Animation wheel
Effect speed
Frost
Channel 22
Animation wheel rotation Blackout move
Zoom
Channel 23
Frost
Animation wheel
Red
Channel 24
Zoom
Animation wheel rotation Green
Channel 25
Red
Frost
Blue
Channel 26
Green
Zoom
Channel 27
Blue
Red
Channel 28
Red fine
Channel 29
Green
Channel 30
Green fine
Channel 31
Blue
Channel 32
Blue fine
