VARYSCAN 4 COMPACT PLUS 575 HMI
Channel 4 color
Channel 5 shutter / dimmer
Channel 6 iris
Channel 7 rotating gobos (positioning and rotating)
Channel 8 effect wheel
channel 1 Pan movement 170°
channel 2 Tilt movement 90°
channel 3 gobo
gobo 0 (Beam) DMX 000 - 031
gobo 1 DMX 032 - 063
gobo 2 DMX 064 - 095
gobo 3 DMX 096 - 127
gobo 4 DMX 128 - 159
gobo 5 DMX 160 - 255
if at DIP-switch No.2 switch 4 is "ON"
gobo 5 DMX 160 - 254
Reset DMX 255
channel 4 colour
colour 0 (white) DMX 000 - 007
colour 1 DMX 008 - 015
colour 2 (red) DMX 016 - 023
colour 3 DMX 024 - 031
colour 4 (yellow) DMX 032 - 039
colour 5 DMX 040 - 047
colour 6 (pink) DMX 048 - 055
colour 7 DMX 056 - 063
colour 8 (green) DMX 064 - 071
colour 9 DMX 072 - 079
colour 10 (orange) DMX 080 - 087
colour 11 DMX 088 - 095
colour 12 (blue) DMX 096 - 103
colour 13 DMX 104 - 111
colour 14 (dark-green) DMX 112 - 119
colour 15 DMX 120 - 127
colour wheel rotation speed 1 (slow) DMX 128 -
colour wheel rotation speed 7 (fast) DMX 255
channel 5 dimmer / shutter
dimmer shutter closed --> blackout (BO) DMX 000
Dimmer 0 – 99% DMX 020 - 127
dimmer open DMX 128 - 137
dimmer shutter immediatelly DMX 138 - 139
shutter sequence 1,00 flashes/sec DMX 140 -
shutter sequence 11,00 flashes/sec DMX 243
shutter open DMX 244 - 255
channel 6 iris
iris (linear) DMX 000 - 255
channnel 7 rotating gobos (positioning and rotation)
0° DMX 000
180° DMX 063
360° DMX 126
540° DMX 191
rotation left (fast) DMX 192
rotation left (slow) DMX 222
rotation stop DMX 223 - 224
rotation right (slow) DMX 225
rotation right (fast) DMX 255
channel 8 effect wheel
open DMX 000 - 031
