32
VARYSCAN 4 COMPACT PLUS 575 HMI
artificial light filter DMX 032 - 063
daylight filter DMX 064 - 095
prism DMX 096 - 111
movable prism (slow) DMX 112 -
movable prism (fast) DMX 127
floodfilter DMX 128 - 159
infinitely variable from flood to open DMX 160 - 255
6 channels (Clay Paky Goldenscan 3 compatible)
channel 1 iris and gobo rotation
channel 2 colour
channel 3 gobo and effect wheel
channel 4 dimmer / shutter
channel 5 pan movement
channel 6 tilt movement
channel 1
iris and gobo rotation
iris closed / gobo first position DMX 000
iris open / gobo first position DMX - 064
second gobo position DMX 065
third gobo position DMX 066
locked into position 180° DMX 106
locked into position 360° DMX 148
locked into position 540° DMX 191
rotation left fast DMX 192
rotation left slow DMX 222
rotation stop DMX 223 - 224
rotation right slow DMX 225
rotation right highest speed DMX 255
channel 2 colour
colour 0 (white) DMX 000 - 007
colour 1 DMX 008 - 015
colour 2 DMX 016 - 023
colour 3 DMX 024 - 031
colour 4 DMX 032 - 039
colour 5 DMX 040 - 047
colour 6 DMX 048 - 055
colour 7 DMX 056 - 063
colour 8 DMX 064 - 071
colour 9 DMX 072 - 079
colour 10 DMX 080 - 087
colour 11 DMX 088 - 095
colour 12 DMX 096 - 103
colour 13 DMX 104 - 111
colour 14 DMX 112 - 119
colour 15 DMX 120 - 127
colour wheel rotation speed (slow) DMX 128 -
colour wheel rotation speed (fast) DMX 255
channel 3 gobo and effect wheel
white DMX 000 - 008
artificial light filter DMX 009 - 017
daylight filter DMX 018 - 026
prism DMX 027 - 035
floodfilter DMX 036 - 044
gobo 1 white DMX 045 - 053
gobo 1 artificial light filter DMX 054 - 062
gobo 1 daylight filter DMX 063 - 071
