35
VARYSCAN 4 COMPACT PLUS 575 HMI
Position of sockets see page 5
DMX-IN DMX-OUT
Pin1:
ground black Pin1: ground black
Pin2: DMX- beige Pin2: DMX- beige
Pin3: DMX+ red Pin3: DMX+ red
Pin4: frei Pin4: frei
Pin5: + 5V green Pin5: frei
Technical data
Measurements: hight 65 cm
width 27 cm
depth 29 cm
Weight: 19 kg
Power consumption: 1725 W
Mains Voltage: 230V 50Hz 7A
Bulb : Osram 575 HMI
Fuse: 8 ampere inert
Change of Eprom/ Software Update
To change the Eprom proceed as follows:
Remove the cover sheet for the electronic board below the mirror by taking out the 4 screws (see sketch page 4).
By comparing the electronic board with the plan of electronic parts you can see the Eprom at the right side (IC U2).
Carefully lever the used Eprom from the holder and exchange it for a new one.
Direction:
Pay attention to the polarity of the Eprom!
(The inlet of the Eprom has to point to the same direction as the inlet of the IC-holder.)
Close the lid and fix it with screws. Plug in your Varyscan
® and please test all functions.
Plan of current circuits for Varyscan ® 4 Compact Plus 575 HMI
