74 1.514 1.416 1.321 6.94 6.71 1.98 1.94
75 1.463 1.367 1.275 7.00 6.77 2.01 1.97
76 1.414 1.321 1.230 7.06 6.83 2.04 2.00
77 1.367 1.276 1.188 7.12 6.88 2.06 2.02
78 1.321 1.233 1.147 7.17 6.94 2.09 2.05
79 1.277 1.191 1.108 7.23 6.99 2.12 2.08
80 1.235 1.151 1.070 7.28 7.04 2.14 2.11
81 1.195 1.113 1.034 7.33 7.09 2.17 2.13
82 1.156 1.076 0.999 7.39 7.14 2.20 2.16
83 1.118 1.041 0.966 7.44 7.18 2.22 2.19
84 1.082 1.007 0.934 7.48 7.23 2.25 2.21
85 1.047 0.974 0.903 7.53 7.27 2.27 2.24
86 1.014 0.942 0.874 7.57 7.31 2.30 2.27
87 0.982 0.912 0.845 7.62 7.35 2.33 2.29
88 0.951 0.883 0.818 7.66 7.39 2.35 2.32
89 0.921 0.855 0.791 7.69 7.43 2.38 2.35
90 0.892 0.828 0.766 7.73 7.46 2.41 2.37
91 0.864 0.802 0.742 7.76 7.49 2.43 2.40
92 0.838 0.777 0.719 7.80 7.52 2.46 2.43
93 0.812 0.753 0.696 7.82 7.54 2.48 2.45
94 0.787 0.730 0.675 7.85 7.57 2.51 2.48
95 0.763 0.708 0.654 7.87 7.59 2.54 2.51
96 0.740 0.686 0.634 7.89 7.61 2.56 2.53
97 0.718 0.666 0.615 7.91 7.62 2.59 2.56
98 0.697 0.646 0.597 7.93 7.63 2.62 2.59
99 0.677 0.627 0.579 7.94 7.64 2.64 2.61
100 0.657 0.609 0.562 7.94 7.65 2.67 2.64
101 0.638 0.591 0.546 7.95 7.65 2.70 2.67
102 0.620 0.574 0.530 7.95 7.65 2.72 2.69
103 0.602 0.558 0.515 7.94 7.64 2.75 2.72
104 0.585 0.542 0.501 7.94 7.63 2.77 2.75
105 0.569 0.527 0.485 7.92 7.92 2.80 2.77
Annex 1
Temp Resistance
˄Kȍ˅
Resist.tol % Temp.tol
ć
˄ć˅
Rmax R
˄t˅Normal
Rmin MAX(+) MIN(-) MAX(+) MIN(-)
-20 116.539 106.732 96.920 9.19 9.19 1.59 1.59
-19 110.231 100.552 91.451 9.63 9.05 1.57 1.57
-18 103.743 94.769 86.328 9.47 8.91 1.56 1.55
-17 97.673 89.353 81.525 9.31 8.76 1.54 1.54
-16 91.990 84.278 77.017 9.15 8.62 1.53 1.52
-15 86.669 79.521 72.788 8.99 8.47 1.51 1.50
-14 81.684 75.059 68.815 8.83 8.32 1.49 1.48
-13 77.013 70.873 65.083 8.66 8.17 1.47 1.47
-12 72.632 66.943 61.574 8.50 8.02 1.45 1.45
-11 68.523 63.252 58.274 8.33 7.87 1.44 1.43
-10 64.668 59.784 55.169 8.17 7.72 1.42 1.41
-9 61.048 56.524 52.246 8.00 7.57 1.40 1.39
-8 57.649 53.458 49.492 7.84 7.42 1.38 1.37
-7 54.456 50.575 46.899 7.67 7.27 1.35 1.35
-6 51.456 47.862 44.455 7.51 7.12 1.33 1.32
-5 48.636 45.308 42.150 7.35 6.97 1.31 1.30
-4 45.984 42.903 39.977 7.18 6.82 1.29 1.28
-3 43.490 40.638 37.927 7.02 6.67 1.27 1.26
-2 41.144 38.504 35.992 6.86 6.52 1.25 1.24
-1 38.935 36.492 34.165 6.70 6.38 1.23 1.21
0 36.857 34.596 32.440 6.53 6.23 1.21 1.19
1 34.898 32.807 30.810 6.38 6.09 1.18 1.17
2 33.055 31.120 29.271 6.22 5.94 1.16 1.15
3 31.317 29.528 27.815 6.06 5.80 1.14 1.12
4 29.681 28.026 26.440 5.90 5.66 1.12 1.10
5 28.138 26.608 25.140 5.75 5.52 1.10 1.08
6 26.682 25.268 23.909 5.60 5.38 1.07 1.06
7 25.310 24.003 22.745 5.45 5.24 1.05 1.03
8 24.016 22.808 21.644 5.30 5.10 1.03 1.01
9 22.794 21.678 20.601 5.15 4.97 1.01 0.99
10 21.641 20.610 19.614 5.00 4.83 0.99 0.97
11 20.553 19.601 18.680 4.86 4.70 0.96 0.94
12 19.525 18.646 17.794 4.71 4.57 0.94 0.92
13 18.554 17.743 16.955 4.57 4.44 0.92 0.90
14 17.636 16.888 16.160 4.43 4.31 0.90 0.88
15 16.769 16.079 15.406 4.29 4.19 0.88 0.85
16 15.949 15.313 14.691 4.15 4.06 0.86 0.83
17 15.174 14.588 14.014 4.02 3.94 0.84 0.81
18 14.442 13.902 13.372 3.89 3.81 0.81 0.79
19 13.748 13.251 12.762 3.75 3.69 0.79 0.76
20 13.093 12.635 12.183 3.62 3.57 0.77 0.74
21 12.471 12.050 11.634 3.50 3.46 0.75 0.72
Widerstand kΩ Temp.
REMKO RXT...DC
