50
C SENSITIVITY: To setup the MOTION SENSITIVITY
• Select SENSITIVITY using the UP or DOWN button. You can adjust the
MOTION SENSITIVITY of a movement from ~4 using the LEFT or RIGHT
button.
() : Most sensitive (highest)
() 4: Least sensitive (lowest)
D TOP / BOTTOM / LEFT / RIGHT: Users can specify MOTION DETECTED area.
• Select TOP, BOTTOM, LEFT or RIGHT using the UP or DOWN button.
You can adjust the AREA using the LEFT or RIGHT button.
() TOP: Extend or reduce the upper area of the MOTION DETECTED area
(8~6)
() BOTTOM: Extend or reduce the bottom area of the MOTION DETECTED
area (8~6)
(3) LEFT: Extend or reduce the left side of the MOTION DETECTED area
(4~9)
(4) RIGHT: Extend or reduce the right side of the MOTION DETECTED area
(4~9)
E INITIAL: To reset the MOTION DETECT mode
• Select INITIAL using the UP or DOWN button. You can reset the MOTION
DETECT mode using the MENU button.
F RETURN: Return to IMAGE ADJ MENU
• Select RETURN using the UP or DOWN button. You can return to IMAGE ADJ
MENU using the MENU button.
TOP
BOTTOM
RIGHT LEFT
reduce RIGHT extend
