7 GB/IE
Assembly
and at the same time fit the open ends of frame
parts A
3 and B 4 together.
Attach the warning sign 9 to the lower frame
with a cable tie 8 (see Fig. C).
When attaching the sign, ensure that the cable
tie
8 also passes around the stand so that the
warning sign 9 cannot slip out of place.
Installing the mat
CAUTION! RISK OF INJURY! Take care
when installing the springs 7 . The springs 7
are under tension and could cause injury.
1) Spread out the mat 1 inside the lower frame
(see Fig. D).
2) Insert the first spring 7 in one of the eyelets
in the mat 1 (see Fig. D).
3) Then insert the other end of the spring in
Position 0 on the lower frame (see Fig. D).
4) Insert another spring 7 in the opposite eyelet
in the mat 1 .
5) Hook the end of the spring in the spring
tensioner 11 and pull the spring 7 towards
the frame. Hook the spring 7 onto the lower
frame in position 32 (see Fig. D).
Proceed in the same way with the remaining
springs
7 and hook them onto the lower frame
one after the other in the following positions:
16 and 48, 8 and 40, 24 and 56 (see Fig. D).
Hook the remaining springs 7 as described
above into the free positions on the lower frame.
Fitting the safety pad
Place the safety pad 2 on the trampoline so
that all the springs 7 as well as the frames A 3
and B 4 (metal parts) are covered.
Fasten the safety pad 2 to the lower frame
by wrapping the strap once around the lower
frame pole. Hook the hook into one of the
eyes of the trampoline mat
1 (see Fig. E).
Note: Do not fasten the strap too tightly.
Ensure that there is still some scope for a
minimum amount of movement.
Now put the continuous outer skirt of the safety
pad over the frame parts A
3 and B 4 .
Fitting the top frame
Fasten the centre poles frame A 13 to the
centre poles (lower frame) 5 in each case
with a fastening (centre pole frame) 22 and
the corresponding fastening set (screw 17 ,
shim 16 , lock nut 18 and cap 19 ) (see Fig. F).
To do this, first remove the screw, the shim and
the lock nut from the fastening
22 . Now guide
the centre pole frame A 13 through the locating
ring of the fastening 22 and connect it to the
centre pole (lower frame) 5 (see Fig. F).
When doing this, place a spacer 15 at the height
of the lower fastening hole. Using the Hexagon
key
12 and the spanner, connect the centre pole
frame A 13 to the centre pole (lower frame) 5
with the screw 17 , shim 16 and lock nut 18 .
Then protect the exposed screw ends with the
caps
19 (see Fig. F).
Fix the connection by fastening the fastening 22
with the screw and the lock nut. The fastening 22
to the centre pole (lower frame) 5 must be
attached at the same height as the small feet
of frame part A (lower frame)
3 (see Fig. F).
Fitting the safety net
Spread out the safety net 21 on the trampoline
mat 1 .
Push the centre poles frame B 14 into the pockets
on the safety net 21 (see Fig. G) so that the
bottom ends of the poles still project.
Fit the centre poles frame B 14 on to the centre
poles frame A 13 (see Fig. H). Ensure that the
safety net does not become trapped. Make
sure that the safety nipple engages.
Insert the hooks of the safety net 21 into the
eyelets on the mat 1 (see Fig. I).
