damage arising from improper use or incor-
rect operation of the tool.
General description
Scope of delivery
Carefully remove the tool from the packag-
ing and check that the following parts are
complete:
• Motor housing with tines and frame tub-
ing
• Right-hand fork with dead-man lever
and permanently fixed mains cable
• Left-hand fork grip
• Plastic cross-plate with cable guide
• Assembly tools, 2 cable clips and belt
clip
• User manual
The major functional parts
are shown on the foldout
pages.
Overview
A
1a Right-hand fork grip with dead-
man lever, safety release catch
and cable tension relief
1b Left-hand fork grip
2 Mains cable
4 Plastic cross-plate
5 Two central tubes
6 Frame tubing
3a Large cable clip
3b Small cable clip
7 Vent
8 Motor housing
9 Gearbox
10 Driveshaft
11 Tines
12 Belt clip
B
13 Bolts provided
14 Screws
15 Wing nuts
C 16 Cable tension relief
17 Safety release catch
18 Dead-man lever
D
19 Hex bolt
20 Self-locking nut
Functional description
Your hand-operated garden tiller is
equipped with a maintenance free electric
motor and a gearbox with sump lubrication.
The tool is fitted with four rotating tine
wheels that automatically dig themselves
into the ground.
The aluminium frame can be folded to aid
storage.
Please refer to the following descriptions for
the function of the controls.
Technical data
FGH 710 A1 Garden Cultivator
Motor power input ........................ 710 W
Rated input voltage ......230 V~, 50 Hz AC
Safety class ........................................ II
Degree of protection ......................... IP24
Working width ...........................360 mm
Max working depth ............ max. 180 mm
Number of tine wheels ...........................4
Nominal rotation rate .......Approx 230 rpm
Weight ...................................... 7.85 kg
Acoustic pressure level (LpA)
.........................71 dB (A); KpA= 2 dB (A)
Measured sound power level (LwA)
........................ 91 dB (A); KwA= 2 dB (A)
Guaranteed sound power level
................................................ 93 dB (A)
Vibration at hand grip (an)
..............................2.7 m/s 2 ; K=1,4 m/s 2
Noise and vibration values have been de-
termined according to the standards and
regulations named in the declaration of
conformity.
Technical and optical alterations may be
made without notice for the purposes of
improvement. No guarantee can be given
