10 FBC 7 A1
Connecting the rain sensor
IMPORTANT
► A jumper 7 is inserted in the terminals 8 on delivery. It must
always be inserted if you are not connecting a rain sensor,
otherwise the programmed watering cannot take place.
► If the jumper is lost, you can bend a new jumper into shape
using standard commercial wire or a paperclip.
NOTICE
► An example of a compatible rain sensor is the Kärcher rain
sensor no. 2.645-037. You should also observe the operat-
ing instructions for the rain sensor.
► Please also note that structural changes to the rain sensor
connecting plug will result in the loss of warranty.
♦ Push the two levers for unlocking the terminals 8 upwards and
remove the jumper 7 .
♦ Insert the cable ends of the rain sensor into the terminals 8
and then clamp them fi rmly by pushing the two levers back
down again.
