Bath Mixer Tap
Proper use
This product is suitable for all pressure-tight hot water
systems such as central heating boilers, instantaneous
water heaters, pressurised boilers and the like. It is
not suitable for low-pressure water heaters such as
wood or coal burning bath geysers, oil or gas bath
geysers, open electrically heated water tanks. If in
doubt please seek the advice of a plumber or heating
engineer. Any use other than that described here or
modification to the product is not permitted and may
lead to damage to persons or property. There is
also the risk of injury and loss of life. The product is
intended for personal use only and not for medical or
commercial use. The manufacturer accepts no liability
for loss or damage arising from improper use.
Description of parts
1 2 S-connectors
2 2 Rosettes
3 2 Sealing rings
4 1 Tap body
4a 1 Changeover button
4b 1 Threaded connector (for the shower hose)
4c 2 Nuts (for S-connectors)
5 1 Mixer nozzle
6 1 Control lever
7 1 Locking screw
8 1 Hot / cold label
9 1 Cartridge end ring
10 1 Cartridge locking ring
11 1 Cartridge
12 1 Setting ring
Technical data
Connection spacing: 135 / 165 mm
Connections (Shower hose): G½”
(approx. 21 mm)
Water connection nut: approx. 30 mm
Hot water temperature: Max.: 85 °C
Operating pressure: Max.: 3 bar
Min.:
0.5 bar
Safety advice
RISK OF LOSS
OF LIFE OR ACCIDENT TO IN-
FANTS AND CHILDREN! Never
leave children unsupervised with the packaging
materials. Danger of suffocation. Keep the product
away from children. The product is not a toy.
CAUTION - RISK OF ELECTRIC
SHOCK! Leaks or the escape of
water can lead to danger to life from
electric shock. Check all connections for leaks
carefully. In addition, ensure that all cables from
electrical devices are correctly and safely installed.
CAUTION! RISK OF INJURY! Please ensure
that no parts are damaged and that all parts are
correctly assembled. Incorrect assembly could
lead to injury. Please note that seals are wear
parts and therefore will require to be replaced
from time to time. Damaged parts could ad-
versely affect safety and proper function.
CAUTION! RISK OF DAMAGE TO
PROPERTY! Have the installation done by
experienced persons only. Leaks or escape of
water can lead to serious damage to buildings
or household fittings and furniture. Check all
connections for leaks carefully.
Ensure that all seals are correctly seated to
prevent leakage of water.
CAUTION! DANGER OF SCALDING!
When making the hot water setting please ensure
that the temperature of the water is not too high.
Before installation, make yourself familiar with
all the existing services, e.g. water connection
and stopcocks.
Please read carefully through these operating
instructions before installing and using the product.
Keep all the safety advice and instructions in a
safe place for future reference!
