4 GB/IE
Installation
Installing the tap
Note: To protect the parts from scratches while
being screwed together cover them with a damp
cloth or use plastic clamps.
Before you start installation turn off the main
water supply to prevent serious leakage of water.
Install the tap at the wall connection as shown
in Figure A.
Connecting the accessories (shower head
and shower hose)*:
Note: So that the parts do not get scratched while
being screwed together, protect them with a damp
cloth or use plastic clamps.
Screw an ordinary shower hose* firmly on to
the thread 4b .
Attach an ordinary shower head* to the
shower hose*.
Observe the installation instructions for the
accessories.
* (not included)
Flushing the tap
The tap must be flushed through before first use
to remove any dirt. To do this, follow these steps
(see Fig. B):
Screw the mixer nozzle 5 off.
Before using the tap for the first time, open the
main water supply. and allow the water to run for
two minutes so that any residues are dissolved
away.
Then screw the mixer nozzle on again.
Operation
Bringing into use
Note: If the tap has not been used for a long period
flush the pipes through thoroughly in order to avoid
stagnation and build-up of residues in the drinking
water supply.
Open the main water supply.
Lift the control lever
6 and swivel it to the right
or left to regulate the strength or temperature
of the water flow.
Hot water:
Swivel the control lever to the left.
Cold water:
Swivel the control lever to the right.
Check that the mixer tap is working properly.
To do this, swivel the lever into all the possible
positions. Please check the connections regularly
for leaks.
Changeover knob water inlet
bath / shower head
Filling the bath:
Press down the changeover button 4a . The
water flows through the mixer nozzle 5 .
Showering:
Lift up the changeover button. The water flows
through the shower hose and the connected
shower head.
Note: If you turn off the water flow using the control
lever
6 then the fitting automatically switches to
bath filling. If you pull the changeover button and
turn in clockwise direction, the shower mode can
be locked at all time (see fig. E).
