26 GB
CAUTION! Do not twist or strain the connection hoses 15 .
Note: This step requires a crosshead screwdriver, a slot screw-
driver and an open-end spanner SW 12 mm.
Follow these steps:
CAUTION! Be sure to only fasten the connecting hoses 15 hand
tight (see Fig. A). Do not use pliers or a wrench. Otherwise the
product could be damaged.
Screw the two connecting hoses 15 hand tight into the designated
boreholes in the fitting body 8 (see Fig. A).
Using a slot screwdriver tighten the threaded bolt 11 all the way
into the fitting body 8 and remove the fastening nut 14 .
Insert section 1 of the pull rod 17 into the back of the fitting body
8 and screw together with section 2 of the pull rod 18 .
Position the fitting body 8 with the fitting base seal 10 inserted
into the opening of your washbasin.
Under the washbasin first place the C-sealing washer 12 , then the
C-metal washer 13 onto the threaded bolt 11 .
Now attach the fastening nut 14 to the threaded bolt 11 and
tighten with an open-end spanner SW 12 mm until the fitting is
seated firmly on the washbasin.
ATTENTION! DANGER OF INJURY, SHEET METAL HAS
SHARP EDGES. To install, temporarily remove the clamping
plate and the eccentric joint
20 .
Unscrew the plastic nut 23 from the eccentric 21 .
Insert the seal in the screw thread of the lower eccentric section 21 a .
Insert the eccentric rod 19 with the ball into the opening and
retighten the plastic nut 23 .
Unscrew the top eccentric section 21 .
Insert the top eccentric section 21 b with the top seal 22 into the
washbasin drain.
