Miomare Single-lever mixer - Handbuch (Seite 30)

30 GB
Deactivating the hot water flow limitation:
Attach the hot water limiting ring 6 as shown in Fig. C / I (neutral
setting).
After adjusting the scald protection, attach the cartridge locknut
5 , the cartridge covering ring 4 and the lever 1 analogue to
the disassembly.
Maintenance and Cleaning
Maintaining and cleaning the tap
Please note that sanitary taps require special care and attention.
Therefore, please follow the instructions:
When cleaning, never use petrol, solvents, aggressive cleansers or
hard cleaning brushes etc. These could damage the surface of the
product.
Dry your taps with a cloth after every use in order to avoid the
build-up of any limescale.
Clean the product with a damp, soft cloth and a mild cleaning
agent if required.
Unscrew and remove the aerator 9 at regular interval and remove
any residues of scale or foreign bodies. If heavily contaminated or
damaged, replace the aerator
9 .
Note: The aerator 9 can normally be unscrewed by hand. Oth-
erwise use an open-end spanner SW 22 mm and be sure to place
a thin, damp cloth around the aerator
9 to prevent damaging it.
A pipe wrench with plastic jaws is also suitable.
Non-observance of the above care advice can be expected to result in
damage to the surfaces of the product. This will void the warranty.
