3 GB/IE
Shower System
 Introduction
Before assembling and using the device
for the first time, take time to familiarise
yourself with the product first. Read the
following assembly instructions and safety instructions
carefully. Only use the product as described and for
the designated areas of application. Please keep
these instructions in a safe place. If you hand this
product on to a third party, you must also pass on
all documents relating to the product.
 Intended Use
Suitable for use with all pressure-resistant hot water
systems such as central heating, continuous-flow water
heater, pressure boiler etc. It is not suitable for low-
pressure water heaters such as wood-fired or coal-
fired hot-water heaters, oil-fired or gas-fired heaters,
open electrical storage heaters. If in doubt, please
consult a plumber or specialist. Any use other than
that described here or modification to the product
is not permitted and may lead to damage to persons
or property. There is also the risk of injury and loss
of life. The product is intended for personal use only
and not for medical or commercial use. The manu-
facturer does not accept any liability for any damage
caused by improper use.
 Description of parts
and features
1 Shower bar
2 Ball head adapter
3 Ball head adapter cover
4 Seal for the overhead shower head
5 Overhead shower head
6 Hand shower head
7 Seal
8 Water-saving seal
9 Screw
10 Shower hose
11
Connection hose for valve
12
Diverter
13
Dowel
14
Wall mount
15
Hand shower head holder
 Supply Scope
Note: Take care when unpacking that you do not
inadvertently throw away any assembly material.
Immediately after unpacking, check that the delivery
is complete and that the product and all its parts are
in perfect condition. Do not under any circumstances
assemble the product if the delivery is incomplete.
1 Shower bar
1 Ball head adapter
1 Ball head adapter cover
1 Seal for the overhead shower head
1 Overhead shower head
1 Hand shower head
4 Seals
1 Water-saving seal
5 Screws
1 Shower hose (approx. 150 cm)
1 Connection hose for valve (approx. 70 cm)
1 Diverter
5 Dowels
2 Wall mounts
1 Hand shower holder
1 Installation instructions
 Technical data
Overhead shower head: Approx. ø 16 cm
Hand shower head:
Approx. ø 9.5 cm,
adjustable - 5 settings
Shower bar: Approx. 102 cm,
stainless steel
Shower hose: Approx. 150 cm, kink-
resistant, stainless steel,
G½“ (approx. 21 mm)
standard connection
