Setting the shower, Cleaning and care, Disposal – Miomare Z31188 Benutzerhandbuch
Seite 5
5
GB/IE
shower holder
15
must be adequately adjustable
in height, too.
5. Determine the desired height of the shower
bar
1
on the wall and mark the hole positions
(see Fig. F).
6. Drill the holes with a 6 mm drill bit and insert
the dowels
13
into the drilled holes (see Fig. F).
7. Place the (prefitted as above) wall mounts
14
over the drilled holes and fasten them in place
with the screws
9
(see Fig. F).
8. Fit the caps to the wall mounts
14
.
9. Screw the diverter
12
with its integral seal on
to the lower thread of the shower bar
1
(see
Fig. G, H).
Ensure that the closed side of the diverter
12
faces left.
10. Screw the connection hose with the G½“
(approx. 21 mm) standard connector for the
valve
11
with the seal
7
to the bottom
threaded hole of the diverter
12
(see Fig. I).
Screw the other end with the seal
7
to your
valve.
Screw the G½“ (approx. 21 mm) shower hose
connection for the hand shower
10
with the
seal
7
on to the threaded hole on the side of
the diverter
12
.
11. Screw the conical end of the shower hose
10
with the seal
7
on to the G½“ (approx. 21 mm)
thread of the hand shower head
6
(see Fig. J).
Note: The Wellness shower system is supplied
with a water-saving seal
8
. Ensure that the
domed side of the water-saving seal
8
is at
the top (see Fig. J).
12. Screw the ball head adapter
2
with the seal
for the overhead shower head
4
on to the
overhead shower head
5
(see Fig. K).
Then place the ball head adapter cover
3
on
to the ball head adapter
2
.
13. Screw the ball head adapter
2
with the
integrated seal
7
on to the top thread of the
shower bar
1
(see Fig. K).
Setting the shower
Use the diverter
12
to set which shower mode
is activated (overhead shower head
5
or hand
shower head
6
).
The angle of the overhead shower head
5
can be set as desired by the user.
The hand shower head
6
has 5 settings:
Normal
Soft
Massage
Mixed jet
Mixed jet
Normal / Soft
Normal / Massage
Cleaning and care
Never use petrol, solvents or aggressive cleaning
agents or hard cleaning brushes, etc. for clean-
ing. They could damage the surface of the
product.
Clean the product with a soft, damp cloth and
use a mild cleaning agent if necessary.
Disposal
The packaging is made entirely of
recyclable materials, which you may
dispose of at local recycling facilities.
Contact your local refuse disposal authority for
more details of how to dispose of your worn-out
product.
