General information and safety notices / Assembly and operation Introduction / General information and safety notices
Avoid the risk
of injury!
Installation must be performed by experts.
Keep the bags and foil of the packaging away
from babies and small children, danger of suf-
focation!
CAUTION! RISK OF INJURY! Please ensure
that no parts are damaged and that all parts
are correctly assembled.
Improper assembly may result in injuries. Dam-
aged parts could impact safety and function.
Do not hold on to or support yourself by the
thermostatic mixer 6 or sliding shower rail 11 .
The materials have not been designed for such re-
sulting forces.
When adjusting the hot water temperature be sure
the water temperature is not too high.
CAUTION! RISK OF SCOLDING! The tem-
perature of the water in the shower can be altered
by adjusting the shower head
3 and the hand
shower head 4 . Please check the water tem-
perature before you enter the water spray jet.
CAUTION! RISK OF INJURY! Please refer
to the operating instructions of your electric drill.
Avoid damage
to property!
CAUTION! WATER DAMAGE! Switch off the
general water supply.
Be sure all seals are correctly seated.
The Mixer Shower is unsuitable for use with
low-pressure tanks and small-scale tank heaters.
We recommend fitting a filter, in order to protect
the incoming end of the tap and, in doing so,
protect the cartridge from damage by foreign
bodies.
The product is only suitable for use in rooms in
which a temperature above 0 °C is maintained.
In case of potential frost, cut off the water supply
and drain the taps.
Any leakage or sudden escape of water can
cause considerable damage to buildings and
property. All connections must therefore be
checked carefully to ensure that they are tight.
Familiarise yourself prior to installation with all
local conditions, e.g. water connections and
shut-off device.
Seals are subject to wear. They must be changed
from time to time.
Before attaching the product to the wall, check
which mounting materials are suitable for your
wall. We have supplied fixings suitable for an
ordinary solid masonry wall.
Assembly and operation
Installation
Note: Please carefully read the fitting instructions
prior to installation. Please note, incorrect installation
will void all warranty – particularly in relation to
subsequent damage.
CAUTION! Shut off the water supply prior to
installation. Before you begin drilling holes for the
mounting plate, check the area to be drilled for con-
cealed supply pipes or cabling, e.g. with a metal /
cable detector. Failure to do so may result in prop-
erty damage.
1. If necessary, roughen the ½" thread (small) of
the S-connectors 10 with an old saw blade.
2. Seal the ½" thread with hemp or sealing tape
(not included in scope of delivery).
3. Screw in the S-connectors 10 so they protrude
from the wall at a right angle. This is required to
prevent the swivel nuts from leaking.
4. Horizontally align the screwed in S-connectors 10
with the clearance of the thermostatic mixer 6 .
5. Screw the collars 8 hand tight onto the S-con-
nectors 10 until they meet the wall. Insert the
plastic silencers 9 into the S-connectors 10 and
tighten the thermostatic mixer 6 with a smooth
spanner SW 30 mm (not with ridged pliers).
Note: Be sure to correctly insert the plastic
silencers
9 into the S-connectors 10 .
Note: With the thermostatic mixer 6 correctly
installed the temperature handle must be on the
right side and the flow control on the left side.
6. Insert a seal 2 into the diverter 7 and screw
onto the thermostatic mixer 6 .
7. Insert one seal 2 in the swivel nut of the shower
rail 11 and screw this to the diverter 7 .
