8 GB/IE
Information / Warranty and Service / Declaration of Conformity Assembly and operation / Maintenance and Cleaning / Disposal / Information
8. Push the hand shower head holder 12 from
above over the shower rail 11 .
9. Select the desired height for the shower head
rail 1 by extending the shower rail 11 accord-
ingly.
10. Drill the holes for the mounting plate 15 .
11. Insert wall plugs 14 into the drilled holes and at-
tach the mounting plate 15 using the screws 16 .
12. Push the covering rosette 17 over the back of
the shower head rail 1 .
13. Using the two socket screws 18 at the bottom of
the shower head rail 1 , attach the shower head
rail 1 to the mounting plate 15 . Next push the
plastic covers 13 over the socket screws 18 .
14. Push the covering rosette 17 over the mounting
plate 15 . Attach the upper part of the shower
rail 11 to the shower head rail 1 .
15. Insert one seal 2 in the swivel nut of the shower
head 3 and screw the shower head 3 to the
shower head rail 1 .
16. Insert the seal 2 in the conical end of the shower
hose 5 and attach this to the hand shower
unit 4 .
17. Insert one seal 2 in the socket screw of the
shower hose 5 and screw this to the thread
of the diverter 7 .
Operation
Note: If the tap has not been used for a longer pe-
riod, flush the pipes thoroughly to avoid stagnation
and build-up of residues.
Adjust the temperature to your preferences using
the temperature handle.
Note: The temperature handle closes off at
approx. 38 °C. For a higher water temperature,
first press the unlock button, then set the temper-
ature handle to the respective temperature.
Use the flow control to adjust the water flow.
Maintenance and Cleaning
Please note that the Mixer Shower requires specific
cleaning and maintenance.
Therefore, please follow the instructions:
Do not use any limescale removing agents, acidic
cleaning agents or scouring agents of any kind.
Do not use corrosive or cleaning agents con-
taining alcohol.
Dry your Mixer Shower with a cloth after every
use in order to avoid the build-up of any lime-
scale.
Clean your Mixer Shower with clean water, mild
detergent and a soft cloth or leather only.
Non-observance of the above care advice can be
expected to result in damage to the surfaces of the
product.
This will inevitably invalidate the guarantee.
Disposal
To protect it from any damage in transit, this tap is
delivered in secure packaging.
The packaging is made of environmen-
tally friendly materials. Please dispose of
them in an environmentally friendly way.
At the end of its life expectancy, do not dispose of
the product with the household waste.
Information regarding environmentally-friendly dis-
posal can be obtained from your municipal or city
administration.
Information
Potability of tap water
Find out about the potability of your mains wa-
ter supply. Your local water authority or water
supply company will be able to inform you.
The following general recommendations apply to
the potability of tap water:
Let the water run freely for a short time if it has
been stagnating in the pipework for more than
four hours.
Do not use any of this stagnant water in the
preparation of food or for drinking. This applies
