7 LSHB 150 A1
GB
IE
Assembly
DANGER
Risk of electrocution from electrical current!
► The electrical installation may only be carried out by an accredited electrician.
► The appropriate standards must be applied during fi tting.
► Switch the electrical circuit off prior to assembly / installation.
WARNING
► When drilling, take care not to damage any pipes/cables in the wall or
ceiling.
► The supplied plugs are only suitable for a mounting on concrete or stone.
Before starting the installation, please check your installation location care-
fully for its suitability for the plugs. If in doubt, call a professional.
NOTICE
► For easier installation the bracket 5 can be unscrewed from the appliance.
♦ Drill two holes with a diameter of 6 mm and a depth of 30 mm at a spacing
of 52 mm.
♦ Insert a plug into each of the holes and screw the appliance with the
bracket
5 to the ceiling or wall (see Fig Ceiling mounting/Wall mounting).
Fig. Wall assembly Fig. Ceiling assembly
