Manual Video 60 Plus Studio
- 8 -
4 Technical specifications
4.1 General data
Tripod / pedestal fitting:
camera fitting:
Max. load:
Weight:
Batteries:
Pan bars :
Tilt angle:
Grades of damping:
Balance plate:
Counterbalance:
Temperature range:
Panning range:
+90 ° / -75 °
horizontally and vertically 9 each and 0
120 mm sliding range
137 Nm (in 18 Steps)
-40 °C to 60 °C
360 °
integrated flat base for all OB tripods
and Multi Disc for Quickfix and
Sachtler pedestals, respectively
V-Plate
65 kg (143 lb)
9,4 kg
3 each 625 U or LR9
two front sections ø 28.5 mm
4.2 Dimensions
200 mm
124 mm
91,5 mm
235 mm
