- 13 -
Video 60 Plus Studio Manual
Caution: The screws always remain inside the head!
A counterbalance spring is dis engaged if the screw's head
is flush with the surface of the housing, i.e. it should not
stick out. The spring is engaged if you can't see the silver
head of the screw anymore because the screw is screwed in
completely.
For reassembling screw the base plate onto the head.
Fasten the allen screws hand-tight.
Guide the balance plate with spindle into the base plate.
Turn the spindle to the right until you can see it coming out
at the front of the head.
Place the fixation screw in the spindles top end and tigh-
ten it. The spindles is now fastened.
Open the tilt safety lock.
