- 9 -
Video 60 Plus Studio Manual
5 The modular system
Due to the Video 60 Plus Studio fluid heads modular design
you may perform certain modifications yourself. In order to
safe time you can do all work with an allen wrench #4 unless
otherwise specified.
The following modifications can be performed:
Á Conversion of the Video 60 Plus Studio to include Touch & Go quick relea-
se system with camera plate 35
Á Conversion of pan bars and rosette
Á
Conversion of Video 60 Plus Studio to include Multi Disc
Á
Conversion of the Video 60 Plus Studio to include half ball
Á Conversion of the Video 60 Plus Studio to include Mitchell
5.1 Conversion of the Video 60 Plus Studio to include
Touch & Go quick release system with camera plate 35
Remove the fixation screw in the spindles top end.
Open the lock of the balance plate and keep on turning
the knob of the spindle to the left until you can remove the
balance plate.
Loosen the 4 screws (now visible) of the base plate under-
neath and remove it.
Take at your hand the EFP set up from the Sachtler
accessory range.
With this set up it is likely that you have to remove the
Touch & Go balance plate from the base plate first.
Release the camera plate from the EFP set up. Grasp the
locking lever with your thumb and index and pulldown the
red safety button.
Move the locking lever as far as possible to the left and
take out the camera plate.
Open the lock of the balance plate by pushing the
red lever underneath the balance plate to the left.
