Parameter values table
Parameter
number
(DDE)
Parameter
name
Filter
Value
Description
2011-05-18 Page 1 of 5
FlowDDE database version
V3.64
6
Arbitrage
temporary busmaster
1
6
Arbitrage
always busmaster
2
6
Arbitrage
automatic busmaster
3
6
Arbitrage
auto busmaster and auto bus optimalization (fast token ring)
67
12
Control mode
setpoint = BUS setpoint
0
12
Control mode
setpoint = analog input
1
12
Control mode
setpoint = master output(FLOW-BUS) * slave factor(FLOW-BUS)
2
12
Control mode
close valve
3
12
Control mode
controller idle (no reaction on changes in sensor signal)
4
12
Control mode
testmode enable (select subject with par 70)
5
12
Control mode
tuningmode enable (select subtject with par 79)
6
12
Control mode
setpoint = 100%
7
12
Control mode
purge valve (fully open)
8
12
Control mode
calibration mode enable (select subject with par 58)
9
12
Control mode
setpoint = master output(analog in) * slave factor(FLOW-BUS)
10
12
Control mode
setpoint = keyboard OR FLOW-BUS setpoint
11
12
Control mode
setpoint = 0%
12
12
Control mode
setpoint = master output(FLOW-BUS) * slave factor(analog in)
13
12
Control mode
(FPP) Range select mode
14
12
Control mode
(FPP) Manual start sensor select, automatic end sensor
15
12
Control mode
(FPP) Automatic start sensor select, manual end sensor
16
12
Control mode
(FPP) Automatic start and end sensor
17
12
Control mode
setpoint = RS232 setpoint
18
12
Control mode
RS232 broadcast mode
19
12
Control mode
valve stearing (valve = setpoint)
20
12
Control mode
analog valve stearing (valve = analog setpoint)
21
12
Control mode
valve safe state
22
22
Sensor type
pressure (controller)
0
22
Sensor type
liquid volume (controller)
1
22
Sensor type
liquid/gas mass (controller)
2
22
Sensor type
gas volume (controller)
3
22
Sensor type
other sensor type (controller)
4
22
Sensor type
pressure (sensor)
128
22
Sensor type
liquid volume (sensor)
129
22
Sensor type
liquid/gas mass (sensor)
130
22
Sensor type
gas volume (sensor)
131
22
Sensor type
other sensor type (sensor)
132
28
Alarm info
&H01
no error message in alarm error status register
0
28
Alarm info
&H01
at least 1 error message in alarm error status register
1
28
Alarm info
&H02
no warning message in alarm warning status register
0
28
Alarm info
&H02
at least 1 warning message in alarm warning status register
1
28
Alarm info
&H04
no minimum alarm message (measure>minimum limit)
0
28
Alarm info
&H04
minimum alarm message for measured signal
1
28
Alarm info
&H08
no maximum alarm message (measure<maximum limit)
0
28
Alarm info
&H08
maximum alarm message for measured signal
1
28
Alarm info
&H10
batch counter has not reached its limit
0
28
Alarm info
&H10
batch counter has reached its limit
1
28
Alarm info
&H20
response O.K. (setpoint-measure within limit)
0
28
Alarm info
&H20
response alarm message: setpoint-measure is too high
1
28
Alarm info
&H40
master output signal O.K. (or not used)
0
28
Alarm info
&H40
master output signal not received: check master instrument
1
28
Alarm info
&H80
hardware O.K.
0
28
Alarm info
&H80
hardware error message: check your hardware
1
44
Operation mode T/A
OFF
0
44
Operation mode T/A
A: MAX & RESP AUTO; T: UP TO LIMIT
1
44
Operation mode T/A
A: MIN & RESP AUTO; T: UP AND REPEAT
2
44
Operation mode T/A
A: MAX & RESP; T: DOWN FROM LIMIT
3
44
Operation mode T/A
A: MIN & RESP; T: DOWN AND REPEAT
4
44
Operation mode T/A
A: MAXIMUM ALARM; T: ALWAYS UP
5
44
Operation mode T/A
A: MINIMUM ALARM
6
44
Operation mode T/A
A: RESPONSE ALARM
7
53
Analog mode
&H3F
0...5 Vdc operation
0
53
Analog mode
&H3F
0...10 Vdc operation
1
53
Analog mode
&H3F
0...20 mA operation
2
53
Analog mode
&H3F
4...20 mA operation
3
53
Analog mode
&H3F
15...20 mA operation
4
53
Analog mode
&H40
Analog input enabled
0
53
Analog mode
&H40
Analog input disabled
1
53
Analog mode
&H80
Analog output enabled
0
53
Analog mode
&H80
Analog output disabled
1
58
Calibration mode
idle: no action
0
58
Calibration mode
adc self calibration
1
58
Calibration mode
dmfc
2
58
Calibration mode
dmfc
3
58
Calibration mode
dmfc
4
58
Calibration mode
dmfc
5
58
Calibration mode
dmfc
6
58
Calibration mode
dmfc
7
58
Calibration mode
dmfc
8
58
Calibration mode
customer zero
9
