Parameter
number
(DDE)
Parameter
name
Group
0
Group
1
Group
2
Process
number
FB
nr
(par)
Var
Type
Var
Length
Min
value
Max
value
Read Write Poll Secured Highly
Secured
Default Value Description
2011-05-18 Page 4 of 5 FlowDDE database version V3.64
DDE str
206 fSetpoint 2 18 33 3 f -3.40282E+38 3.40282E+38 Yes Yes No No No 0 setpoint: wanted value for direct reading (in capunits, max.= capacity) fSetpoint
207 Mass 20 33 23 f -3.40282E+38 3.40282E+38 Yes No Yes No No 0 Mass in g Mass
208 Manufacturer status register 4 119 1 c 8 Yes No No No No Manufacturer Status register (64 diagnostic bits) Mstatus
209 Manufacturer warning register 4 119 2 c 8 Yes No No No No Manufacturer Warning register (64 diagnostic bits) Mwarning
210 Manufacturer error register 4 119 3 c 8 Yes No No No No Manufacturer Error register (64 diagnostic bits) Merror
211 Diagnostic history string 4 119 4 c -2 Yes Yes No No No Diagnostic history string (contains history of diag codes) DiagHist
212 Diagnostic mode 4 119 5 c 0 255 Yes Yes No Yes No 0 Diagnostic mode (0 = diagnostics off, 1 = diagnostics on) DiagMode
213 Manufacturer status enable 4 119 6 c 0 255 No Yes No No No 0 Manufacturer Status enable (0-127 or 254 = disable all, 255 = enable all) MStatEnabl
214 Analog output zero adjust 10 116 21 f -3.40282E+38 3.40282E+38 Yes Yes No Yes No 0 Analog measure output, zero adjust AnOutZA
215 Analog output span adjust 10 116 22 f -3.40282E+38 3.40282E+38 Yes Yes No Yes No 1 Analog measure output, span adjust AnOutSA
216 Analog input zero adjust 10 116 23 f -3.40282E+38 3.40282E+38 Yes Yes No Yes No 0 Analog setpoint input, zero adjust AnInZA
217 Analog input span adjust 10 116 24 f -3.40282E+38 3.40282E+38 Yes Yes No Yes No 1 Analog setpoint input, span adjust AnInSA
218 Sensor input zero adjust 10 116 25 f -3.40282E+38 3.40282E+38 Yes Yes No Yes No 0 Sensor input, zero adjust SensInZA
219 Sensor input span adjust 10 116 26 f -3.40282E+38 3.40282E+38 Yes Yes No Yes No 1 Sensor input, span adjust SensInSA
220 Temperature input zero adjust 10 116 27 f -3.40282E+38 3.40282E+38 Yes Yes No Yes No 0 Sensor temperature input, zero adjust TempInZA
221 Temperature input span adjust 10 116 28 f -3.40282E+38 3.40282E+38 Yes Yes No Yes No 1 Sensor temperature input, span adjust TempInSA
222 Adaptive smoothing factor 6 117 5 f 0 1 Yes Yes No Yes No 1.0 Sensor input filter adapt setting ExpSmooAd
223 Slope setpoint step 18 33 24 i 0 32000 Yes Yes No Yes No 32000 Slope setpoint step. Setpoint step for the given slopetime SlopeSetp
224 Filter length 6 117 6 i 0 255 Yes Yes No Yes No 1 Number of samples for average filter FilterLen
225 Absolute accuracy 2 33 25 f -3.40282E+38 3.40282E+38 Yes No No No No 0 Actual accuracy in current unit fAccuracy
226 Lookup table index 3 33 26 c 0 255 Yes Yes No No No 0 Lookup table for linearisation index (x and y direction) LookI
227 Lookup table X 3 33 27 f -3.40282E+38 3.40282E+38 Yes Yes No Yes No 0 Lookup table for linearisation x LookX
228 Lookup table Y 3 33 28 f -3.40282E+38 3.40282E+38 Yes Yes No Yes No 0 Lookup table for linearisation y LookY
229 Lookup table temperature index 3 33 29 c 0 255 Yes Yes No No No 0 Lookup table for linearisation at certain temperature index (z direction) LookTempI
230 Lookup table temperature 3 33 30 f -273.15 3.40282E+38 Yes Yes No Yes No 0 Lookup table for linearisation at certain temperature (z) LookTemp
231 Valve maximum 8 114 25 f 0 24 Yes Yes No Yes No 0.2 Maximum current/voltage for valve ValveMax
232 Valve mode 8 114 26 c 0 255 Yes Yes No Yes No 1 Valve output mode selection ValveMode
233 Valve open correction 8 114 27 f 0 1.5 Yes Yes No Yes No 0.96 Valve open current/voltage correction (example: 0.96, Open = ValveOpen * 0.96) VlvOpenCor
234 Valve zero hold 8 114 28 f 0 1 Yes Yes No Yes No 0 Valve hold current/voltage at %0 setp (example: 0.8, Hold = ValveOpen * 0.8) VlvZeroHld
235 Valve slope 8 114 29 f 0 50 Yes Yes No Yes No 0.009 Valve slope time (seconds) ValveSlope
236 IFI data 23 0 21 c -2 Yes Yes No No No 0 IFI data dump protocol communication string IFIData
237 Range used 20 19 115 20 c -2 0 99 Yes No Yes No No 0 Piston Prover information about used sensors RangeUsed
238 Fluidset properties 3 33 31 c 0 255 Yes Yes No Yes Yes 0 Fluidset properties FldSetProp
239 Lookup table unit type index 3 33 12 c 0 255 Yes Yes No Yes Yes 0 Lookup table unit type LUnitType
240 Lookup table unit type 3 33 13 c 20 Yes Yes No Yes Yes Lookup table unit type name LUnTypName
241 Lookup table unit index 3 33 16 c 0 255 Yes Yes No Yes Yes 0 Lookup table unit (unit LUTy) LUnit
242 Lookup table unit 3 33 17 c 7 Yes Yes No Yes Yes kg/s Lookup table unit name LUnitName
243 Capacity unit type index 3 29 c 0 255 Yes Yes No Yes No 0 Capacity (readout) unit type CUnitType
244 Capacity unit type 3 30 c 20 Yes Yes No Yes No Capacity (readout) unit type name CUnTypName
245 Capacity unit type temperature 3 33 10 f -273.15 3.40282E+38 Yes Yes No Yes No 0 Capacity (readout) unit type temperature (°C) CUnTypTemp
246 Capacity unit pressure 3 33 11 f 0 3.40282E+38 Yes Yes No Yes No 1 Capacity (readout) unit type pressure (bar (a)) CUnTypPres
247 Capacity minimum 3 27 f -3.40282E+38 3.40282E+38 Yes Yes No Yes No 0 Minimum capacity in output capacity units CapMin
248 Capacity maximum 3 28 f -3.40282E+38 3.40282E+38 Yes Yes No Yes No 1 Maximum capacity in output capacity units CapMax
249 Formula type 3 113 17 i 0 65535 Yes Yes No Yes No 0 Formula type needed for conversion FormulaTyp
250 Heat capacity 3 113 18 f 0 3.40282E+38 Yes Yes No Yes No 0 Heat capacity (Cp) (sensor conditions) HeatCap
251 Thermal conductivity 3 113 20 f 0 3.40282E+38 Yes Yes No Yes No 0 Thermal conductivity (sensor conditions) ThermCond
252 Viscosity 3 113 21 f 0 3.40282E+38 Yes Yes No Yes No 0 Dynamic viscosity (fluid conditions) Viscosity
253 Standard flow 3 113 22 f -3.40282E+38 3.40282E+38 Yes Yes No Yes No 1 Standard mass flow in ln/min (20°C, 1.01325 bar (a) ) air or g/h H2O equivalent NormMasFlw
254 Controller speed 8 3 114 30 f 0 3.40282E+38 Yes Yes No Yes No 1 Controller speed factor (gain) Kspeed
255 Sensor code 13 113 23 i 0 65535 Yes Yes No Yes Yes 0 Sensor code SensorCode
256 Sensor configuration code 13 113 24 c 0 255 Yes Yes No Yes Yes 0 Sensor configuration code SensorRevC
257 Restriction code 13 113 25 i 0 65535 Yes Yes No Yes Yes 0 Restriction code RestrCode
258 Restriction configurator code 13 113 26 c 0 255 Yes Yes No Yes Yes 0 Restriction configuration code RestrRevC
259 Restriction NxP 13 113 27 l 0 2147483648 Yes Yes No Yes Yes 0 Restriction NxP (proportional to air equivalent capacity of LFE) RestrNxP
260 Seals information 13 113 28 c 16 0 255 Yes Yes No Yes Yes V,V Seals information (1st byte = other, 2nd = plunger seal) Seals
261 Valve code 13 113 29 i 0 65535 Yes Yes No Yes Yes 0 Valve code ValveCode
262 Valve configuration code 13 113 30 c 0 255 Yes Yes No Yes Yes 0 Valve configuration code ValveRevC
263 Instrument properties 13 113 31 l 0 2147483648 Yes Yes No Yes Yes 0 Instrument properties InstrProp
264 Lookup table frequency index 3 116 10 c 0 1 Yes Yes No Yes No 0 Lookup table for frequency index LookFreqI
265 Lookup table frequency frequency 3 116 11 f -3.40282E+38 3.40282E+38 Yes Yes No Yes No 0 Lookup table for frequency frequency LFFreq
266 Lookup table frequency temperature 3 116 12 f -273.15 3.40282E+38 Yes Yes No Yes No 0 Lookup table for frequency temperature LFTemp
267 Lookup table frequency density 3 116 13 f -3.40282E+38 3.40282E+38 Yes Yes No Yes No 0 Lookup table for frequency density LFDensity
268 Lookup table frequency span adjust 3 116 14 f -3.40282E+38 3.40282E+38 Yes Yes No Yes No 0 Lookup table for frequency span adjust LFSpanAdj
269 Capacity unit index (ext) 3 19 65 15 c 0 255 Yes Yes No Yes No 0 Capacity (readout) unit index (extended unit table) CUnit
270 Density actual 3 116 15 f -3.40282E+38 3.40282E+38 Yes No Yes No No 0 Actual density, measured by instrument DensityAct
271 Measured restriction 13 116 18 f 0 3.40282E+38 Yes Yes No Yes No 0 Measured restriction RestrMeas
272 Temperature potmeter 3 116 8 c 0 255 Yes Yes No Yes No 0 Potmeter for sensor temperature compensation TempPotm
273 Temperature potmeter gain 3 116 9 c 0 255 Yes Yes No Yes No 0 Gain for sensor temperature compensation TempGain
274 Counter controller overrun correction 16 104 10 f 0 3.40282E+38 Yes Yes No No No 1 Counter controller overrun correction CntrCConv
275 Counter controller gain 16 104 11 f 0 3.40282E+38 Yes Yes No No No 1 Counter controller gain CntrCGain
