Parameter
number
(DDE)
Parameter
name
Filter
Value
Description
2011-05-18 Page 4 of 5
FlowDDE database version
V3.64
166
Controller features
&H04
fixed monitor output signal
0
166
Controller features
&H04
monitor output changed at setpoint steps
1
166
Controller features
&H08
voltage drift compensation for valve output turned on
0
166
Controller features
&H08
voltage drift compensation for valve output turned off
1
166
Controller features
&H10
auto slope disabled
0
166
Controller features
&H10
auto slope enabled for pilot valves
1
166
Controller features
&H20
automatic correction for valve open turned on
0
166
Controller features
&H20
automatic correction for valve open turned off
1
166
Controller features
&H40
controller special mode (valve output steps) turned off
0
166
Controller features
&H40
controller special mode (valve output steps) turned on
1
166
Controller features
&H80
valve overshoot protection turned off
0
166
Controller features
&H80
valve overshoot protection turned on
1
175
Identification number
UFO?: Unidentified FLOW-BUS Object
0
175
Identification number
RS232/FLOW-BUS interface
1
175
Identification number
PC(ISA) interface
2
175
Identification number
ADDA4 (4 channels)
3
175
Identification number
R/C-module, 32 channels
4
175
Identification number
T/A-module
5
175
Identification number
ADDA1: 1 channel ADDA converter module
6
175
Identification number
DMFC: digital mass flow controller
7
175
Identification number
DMFM: digital mass flow meter
8
175
Identification number
DEPC: digital electronic pressure controller
9
175
Identification number
DEPM: digital electronic pressure meter
10
175
Identification number
ACT: single actuator
11
175
Identification number
DLFC: digital liquid flow controller
12
175
Identification number
DLFM: digital liquid flow meter
13
175
Identification number
DSCM-A: digital single channel module for analog instruments
14
175
Identification number
DSCM-D: digital single channel module for digital instr.
15
175
Identification number
FRM: FLOW-BUS rotor meter (calibration-instrument)
16
175
Identification number
FTM: FLOW-BUS turbine meter (calibration-instrument)
17
175
Identification number
FPP: FLOW-BUS piston prover/tube (calibration-instrument)
18
175
Identification number
F/A-module: special version of T/A-module
19
175
Identification number
DSCM-E: evaporator controller module (single channel)
20
175
Identification number
DSCM-C: digital single channel module for calibrators
21
175
Identification number
DDCM-A: digital dual channel module for analog instruments
22
175
Identification number
DMCM-D: digital multi channel module for digital instruments
23
175
Identification number
Profibus-DP/FLOW-BUS interface module
24
175
Identification number
FLOW-BUS Coriolis Meter
25
175
Identification number
FBI: FLOW-BUS Balance Interface
26
175
Identification number
CORIFC: CoriFlow Controller
27
175
Identification number
CORIFM: CoriFlow Meter
28
175
Identification number
FICC: FLOW-BUS Interface Climate Control
29
175
Identification number
IFI: Instrument FLOW-BUS Interface
30
175
Identification number
KFI: Keithley FLOW-BUS Interface
31
175
Identification number
FSI: FLOW-BUS Switch Interface
32
175
Identification number
MSCI: Multi-Sensor/Confroller Interface
33
175
Identification number
APP-D: Active Piston Prover
34
175
Identification number
LFI: Leaktester FLOW-BUS Interface
35
185
Device function
Unknown
0
185
Device function
Interface
1
185
Device function
ADDA
2
185
Device function
Operator
3
185
Device function
Supervisor (totalizer/alarm)
4
185
Device function
Controller
5
185
Device function
Meter
6
185
Device function
Special
7
185
Device function
(Protocol) converter
8
197
Calibrations options
&H01
Automatic capacity setting for optimal resolution
0
197
Calibrations options
&H01
Manual capacity setting for optimal resolution
1
197
Calibrations options
&H02
Barometer value input via parameter 107: BaroPress
0
197
Calibrations options
&H02
Barometer is master; input automatically from master
1
200
Interface configuration
Configuration A: 14 ch. Standard parms. with network scan
0
200
Interface configuration
Configuration B: 14 ch. Standard parms with fixed chan list
1
200
Interface configuration
Configuration C: 7 ch. Extended parms with fixed chan list
2
200
Interface configuration
Configuration D: 11 ch. Extended parms with network scan
3
208
Manufacturer status regi
&H800000
No diagnostics available in manufacturer status register
0
208
Manufacturer status regi
&H800000
Diagnostics available in manufacturer status register
1
209
Manufacturer warning re
&H800000
No diagnostics available in manufacturer warning register
0
209
Manufacturer warning re
&H800000
Diagnostics available in manufacturer warning register
1
210
Manufacturer error regis
&H800000
No diagnostics available in manufacturer error register
0
210
Manufacturer error regis
&H800000
Diagnostics available in manufacturer error register
1
212
Diagnostic mode
Debug mode off
0
212
Diagnostic mode
Debug mode on
1
213
Manufacturer status ena
set status bit (range 0…127)
0
213
Manufacturer status ena
set status bit (range 0…127)
127
213
Manufacturer status ena
clear all status bits
254
213
Manufacturer status ena
set all status bits
255
232
Valve mode
voltage drive mode
0
232
Valve mode
current drive mode
1
238
Fluidset properties
&H01
Fluidset is disabled
0
238
Fluidset properties
&H01
Fluidset is enabled
1
238
Fluidset properties
&H02
Fluidset is not set by Bronkhorst High-Tech
0
238
Fluidset properties
&H02
Fluidset is set by Bronkhorst High-Tech
2
238
Fluidset properties
&H04
Fluidset is not calibrated on actual gas
0
