Bronkhorst RS232 interface - Handbuch (Seite 35)

Parameter
number
(DDE)
Parameter
name
Filter Value Description
2011-05-18 Page 2 of 5 FlowDDE database version V3.64
58 Calibration mode adjust Vref output by connecting it to analog in 10
58 Calibration mode adjust analog out by connecting it to analog in 11
58 Calibration mode adjust valveoutput by connecting it to analog in 12
58 Calibration mode dmfc 13
58 Calibration mode dmfc 14
58 Calibration mode analog output = 0 % 15
58 Calibration mode analog output = 100 % 16
58 Calibration mode analog output = 50 % 17
58 Calibration mode factory zero 18
58 Calibration mode sensor differentiator (setpoint steps are needed!) 19
58 Calibration mode automatic sensor configuration 20
58 Calibration mode sensor temperature calibration 21
58 Calibration mode customer zero (no control mode 9 needed) 22
58 Calibration mode Error mode (result of previous cal mode) 255
60 Monitor mode (filtered) setpoint 0
60 Monitor mode controller error input signal / raw sensor signal 1
60 Monitor mode controller output signal to valve 2
60 Monitor mode sensor signal slow 3
60 Monitor mode sensor signal slow filtered 4
60 Monitor mode linearization output 5
60 Monitor mode differentiator output 6
60 Monitor mode differentiator output filtered 7
60 Monitor mode normal sensor signal (Output) 8
60 Monitor mode analog input signal 9
60 Monitor mode power supply voltage 10
60 Monitor mode mass flow in display unit (normally ln/min) 11
60 Monitor mode volume flow in l/min 12
60 Monitor mode temperature in °C 13
60 Monitor mode pressure absolute in mbara 14
60 Monitor mode time in msec/frequency in Hz. 15
60 Monitor mode calibrated volume at actual sensor in ml 16
60 Monitor mode delta-P pressure in mbarg 17
60 Monitor mode atmospheric (barometer) pressure in mbara 18
60 Monitor mode mass flow in kg/min 19
61 Alarm register1 &H8000000000000000 No diagnostics available in warning register 0
61 Alarm register1 &H8000000000000000 Diagnostics available in warning register 1
62 Alarm register2 &H8000000000000000 No diagnostics available in error register 0
62 Alarm register2 &H8000000000000000 Diagnostics available in error register 1
67 ADC control register &H001000 ADC bipolar mode 0
67 ADC control register &H001000 ADC unipolar mode 1
67 ADC control register &H1000000 Disable zero measure threshold 0
67 ADC control register &H1000000 Enable zero measure threshold 1
67 ADC control register &H1C0000 ADC gain = 1x 0
67 ADC control register &H1C0000 ADC gain = 2x 1
67 ADC control register &H1C0000 ADC gain = 4x 2
67 ADC control register &H1C0000 ADC gain = 8x 3
67 ADC control register &H1C0000 ADC gain = 16x 4
67 ADC control register &H1C0000 ADC gain = 32x 5
67 ADC control register &H1C0000 ADC gain = 64x 6
67 ADC control register &H1C0000 ADC gain = 128x 7
69 <AlarmEnble> disable 0
69 <AlarmEnble> enable 1
70 Test mode idle; no action 0
70 Test mode uProcessor 1
70 Test mode IO 2
70 Test mode RAM 3
70 Test mode FRAM 4
70 Test mode ADC 5
70 Test mode DAC 6
70 Test mode sensor 7
70 Test mode valve drive circuit 8
70 Test mode Vref 9
70 Test mode FLOW-BUS 10
70 Test mode calibration 11
70 Test mode keyboard 12
71 <ADC channel select> AD channel 1 1
71 <ADC channel select> AD channel 2 2
79 Tuning mode idle; no action 0
79 Tuning mode sensor 1
79 Tuning mode valve 2
79 Tuning mode Fuzzy controller normal operation 3
79 Tuning mode Fuzzy controller open at zero 4
79 Tuning mode PID controller 5
80 Valve default normally closed 0
80 Valve default normally opened 1
80 Valve default normally closed inverse controlled 2
80 Valve default normally opened inverse controlled 3
80 Valve default remain position 4
86 IO status &H01 read diagnostic jumper (no diagnostics, read/write) 1
86 IO status &H02 not used 1
86 IO status &H04 read analog jumper (use cntrlmode, read/write) 1
86 IO status &H08 read micro switch (read/write) 1
86 IO status &H10 diagnostic jumper set (read only) 1
86 IO status &H20 initialization jumper set (read only) 1
