Parameter
number
(DDE)
Parameter
name
Filter Value Description
2011-05-18 Page 3 of 5 FlowDDE database version V3.64
86 IO status &H40 analog jumper set (read only) 1
86 IO status &H80 micro switch pressed (read only) 1
106 Pressure sensor type delta-P 0..5" W.C. 0
106 Pressure sensor type delta-P 0...10" W.C. 1
106 Pressure sensor type absolute pressure 800-1200 mbar 2
106 Pressure sensor type absolute pressure 800-1100 mbar 3
106 Pressure sensor type delta-P -5...0 "W.C. 4
106 Pressure sensor type delta-P -10...0 "W.C. 5
106 Pressure sensor type delta-P -10...+10 "W.C. 6
106 Pressure sensor type delta-P 0...1 PSI 7
106 Pressure sensor type delta-P -1...0 PSI 8
106 Pressure sensor type absolute pressure 0-10 bar 10
114 Reset no reset 0
114 Reset reset counter value (no mode change) or common reset 1
114 Reset reset alarm 2
114 Reset restart batch counter 3
114 Reset reset counter value (counter off) 4
114 Reset Reset module (soft reset) 5
118 Alarm mode off 0
118 Alarm mode alarm on absolute limits 1
118 Alarm mode alarm on limits related to setpoint (response alarm) 2
118 Alarm mode alarm when instrument powers-up (eg. after power-down) 3
119 Alarm output mode no relais activity at alarm 0
119 Alarm output mode relais pulses until reset 1
119 Alarm output mode relais activated until reset 2
120 Alarm setpoint mode no setpoint change at alarm 0
120 Alarm setpoint mode new/safe setpoint at alarm enabled (set at par 121) 1
125 Counter output mode no relais activity at batch limit 0
125 Counter output mode relais pulses after reaching batch limit until reset 1
125 Counter output mode relais activated after reaching batch limit until reset 2
126 Counter setpoint mode setpoint change at batch limit disabled 0
126 Counter setpoint mode setpoint change at batch limit enabled 1
130 Counter mode off 0
130 Counter mode counting upwards continuously 1
130 Counter mode counting up to limit (batchcounter) 2
147 Range select calibration ready/stop 0
147 Range select run calibration until stopsensor 1/select range 1 1
147 Range select run calibration until stopsensor 2/select range 2 2
147 Range select run calibration until stopsensor 3/select range 3 3
147 Range select run calibration until stopsensor 4/select range 4 4
147 Range select run calibration and select range 5 5
147 Range select run calibration with automatic range selection 9
147 Range select run until stopsensor 1 until 3 values between limit 19
147 Range select run until stopsensor 2 until 3 values between limit 29
147 Range select run until stopsensor 3 until 3 values between limit 39
147 Range select run until stopsensor 4 until 3 values between limit 49
147 Range select run and select range 5 until 3 values between limit 59
147 Range select run with auto-select + 3 values between limit 99
156 Reset alarm enable no reset possible 0
156 Reset alarm enable reset: keyboard 1
156 Reset alarm enable reset: external 2
156 Reset alarm enable reset: keyboard or external 3
156 Reset alarm enable reset: FLOW-BUS 4
156 Reset alarm enable reset: FLOW-BUS or keyboard 5
156 Reset alarm enable reset: FLOW-BUS or external 6
156 Reset alarm enable reset: FLOW-BUS or keyboard or external 7
156 Reset alarm enable reset: automatic 8
156 Reset alarm enable reset: automatic or keyboard 9
156 Reset alarm enable reset: automatic or external 10
156 Reset alarm enable reset: automatic or keyboard or external 11
156 Reset alarm enable reset: automatic or FLOW-BUS 12
156 Reset alarm enable reset: automatic or FLOW-BUS or keyboard 13
156 Reset alarm enable reset: automatic or FLOW-BUS or external 14
156 Reset alarm enable reset: automatic or FLOW-BUS or keyboard or external 15
157 Reset counter enable no reset possible 0
157 Reset counter enable reset: keyboard 1
157 Reset counter enable reset: external 2
157 Reset counter enable reset: keyboard or external 3
157 Reset counter enable reset: FLOW-BUS 4
157 Reset counter enable reset: FLOW-BUS or keyboard 5
157 Reset counter enable reset: FLOW-BUS or external 6
157 Reset counter enable reset: FLOW-BUS or keyboard or external 7
157 Reset counter enable reset: automatic 8
157 Reset counter enable reset: automatic or keyboard 9
157 Reset counter enable reset: automatic or external 10
157 Reset counter enable reset: automatic or keyboard or external 11
157 Reset counter enable reset: automatic or FLOW-BUS 12
157 Reset counter enable reset: automatic or FLOW-BUS or keyboard 13
157 Reset counter enable reset: automatic or FLOW-BUS or external 14
157 Reset counter enable reset: automatic or FLOW-BUS or keyboard or external 15
166 Controller features &H01 valve in normal position after startup 0
166 Controller features &H01 valve in safe position after startup 1
166 Controller features &H02 open from zero with PID output to valve 0
166 Controller features &H02 open from zero with ramp output to valve 1
