Parameter
number
(DDE)
Parameter
name
Group
0
Group
1
Group
2
Process
number
FB
nr
(par)
Var
Type
Var
Length
Min
value
Max
value
Read Write Poll Secured Highly
Secured
Default Value Description
2011-05-18 Page 3 of 5 FlowDDE database version V3.64
DDE str
136 <inputnode> 17 5 c 0 128 Yes Yes No Yes No 3 physical node address for channel number inputnode
137 <inputproc> 17 6 c 0 128 Yes Yes No Yes No 1 physical process for channel number inputproc
138 <RCreadunit> 17 7 c 7 Yes No No No No ln/min readout unit for direct reading (local variable on module: read only) RCreadunit
139 Slave factor 18 33 1 f 0 500 Yes Yes No No No 100.0 slave factor for master slave control (setp = master output * slave factor) SlaveFact%
140 Reference voltage input 18 33 2 i 0 65535 Yes No Yes No No 0 reference voltage input for setpoint signal VrefInput
141 Stable situation controller response 8 114 17 c 0 255 Yes Yes No Yes No 0 controller response when controller is stable: |measure-setpoint| < 2% RespStable
142 Temperature 19 13 33 7 f -250 500 Yes Yes Yes No No 20 absolute temperature in degrees Celsius temperatur
143 Pressure 19 13 33 8 f -3.40282E+38 3.40282E+38 Yes Yes Yes No No 1013.25 absolute pressure in mbar pressure
144 Time 19 33 9 f 0 3.40282E+38 Yes No Yes No No 0 time in milliseconds time
145 Calibrated volume 19 33 10 f 0 3.40282E+38 Yes Yes No Yes No 50 calibrated volume in litres calvolume
146 Sensor number 19 16 c 0 4 Yes Yes Yes No No 0 pointer to sensor number in calibration tube (FPP) sensornr
147 Range select 20 19 115 10 c 0 99 Yes Yes Yes No No 0 Piston Prover operation mode (write) and status information (read back) rangeselct
148 Time out 20 2 i 0 30000 Yes Yes No Yes No 0 maximum admitted duration time for specific procedure (in 100 ms) TimeOut
149 Frequency 21 33 9 f 0 100000 Yes No Yes No No 0 frequency in Hz frequency
150 Impulses/m3 20 33 10 f 0 3.40282E+38 Yes Yes No Yes No 42773.4 For FRM and FTM imp/m3 and for FCM imp/kg imp/m3
151 Normal volume flow 19 33 5 f 0 3.40282E+38 Yes No No No No 0 volume flow referenced to normal conditions i.e. 0 °C, 1013.25 hPa(a) in ln/min RefVolFlow
152 Volume flow 19 33 6 f -3.40282E+38 3.40282E+38 Yes No No No No 0 volume flow at actual conditions in l/min volumeflow
153 Delta-p 19 33 11 f -100000 100000 Yes Yes Yes No No 0 relative pressure between atmosphere and sensor position delta-p
154 <scalefact> 21 33 13 i 1 10000 Yes No No No No 1 scaling factor (multiplication) for readout on display (for optimal resolution) scalefact
155 Sensor name 19 17 c 10 Yes Yes No Yes No SENSOR0 label with information about stop sensor sensorname
156 Reset alarm enable 15 97 9 c 0 255 Yes Yes No No No 15 enable reset of alarm by: keyboard, external signal, FLOW-BUS, automatic RstAlarmEn
157 Reset counter enable 16 104 9 c 0 255 Yes Yes No No No 7 enable reset of counter by: keyboard, external signal, FLOW-BUS, automatic RstCountEn
158 Master node 18 33 14 c 1 128 Yes Yes No No No 3 node number of master instrument output signal for a slave MasterNode
159 Master process 18 33 15 c 1 128 Yes Yes No No No 1 process number of master instrument output signal for a slave MasterProc
160 Remote instrument node 18 33 16 c 1 128 Yes Yes No Yes No 3 node number of instrument to be operated by another module (keyboard/display) InstrNode
161 Remote instrument process 18 33 17 c 1 128 Yes Yes No Yes No 1 process number of instrument to be operated by another module (keyboard/display) InstrProc
162 Minimum custom range 3 33 18 f -3.40282E+38 3.40282E+38 Yes Yes No Yes No 0.0 Mnimum value at 0% for special user readout unit RangeMin
163 Maximum custom range 3 33 20 f -3.40282E+38 3.40282E+38 Yes Yes No Yes No 100.0 Maximum value at 100% for special user readout unit RangeMax
164 Relay/TTL output 12 115 11 c 0 255 Yes Yes No Yes No 0 Relay/TTL output setting (disabled when used by alarm or counter) Relay/TTL
165 Open from zero controller response 8 114 18 c 0 255 Yes Yes No Yes No 0 Controller response when valve opens from zero RespOpen0%
166 Controller features 8 114 20 c 0 255 Yes Yes No Yes No 1 Controller settings for special purpose ContrType
167 PID-Kp 8 3 114 21 f 0 3.40282E+38 Yes Yes No Yes No 10 PID factor Kp PIDKp
168 PID-Ti 8 114 22 f 0 3.40282E+38 Yes Yes No Yes No 0.05 PID factor Ti PIDTi
169 PID-Td 8 114 23 f 0 3.40282E+38 Yes Yes No Yes No 0 PID factor Td PIDTd
170 Density 3 33 21 f 0 3.40282E+38 Yes Yes No Yes No 1.293 Density of selected fluid in kg/m3 Density
171 Calibration certificate 13 3 113 8 c -2 Yes Yes No Yes Yes Number of calibration certificate (last basic calibration) CalCertNr
172 Calibration date 13 3 113 9 c 8 Yes Yes No Yes Yes 19991231 Date of last (basic) calibration CalDate
173 Service number 13 113 10 c 15 Yes Yes No Yes Yes 00000000 Service number for repair/rebuilding/recalibration ServiceNr
174 Service date 13 113 11 c 8 Yes Yes No Yes Yes 19991231 Date of last service action ServDate
175 Identification number 13 113 12 c 0 255 Yes Yes No Yes Yes 7 Identification number (type) of instrument/device IdentNr
176 BHT11 14 118 11 c 0 255 No Yes No Yes Yes 0 special BHT parameter (to be changed by Bronkhorst only) BHT11
177 Power mode 12 115 12 c 0 50 Yes Yes No Yes No 0 power supply indication in Vdc PowerMode
178 Pressure inlet 13 3 113 13 f -100000 100000 Yes Yes No Yes No 3 pressure inlet (upstream) of fluid in bara (for first fluidnr only) Pupstream
179 Pressure outlet 13 3 113 14 f -100000 100000 Yes Yes No Yes No 1 pressure outlet (downstream) of fluid in bara (for first fluidnr only) Pdownstrm
180 Orifice 13 113 15 f 0 1000 Yes Yes No Yes No 1 orifice diameter in mm Orifice
181 Fluid temperature 13 3 113 16 f -273.15 3.40282E+38 Yes Yes No Yes No 20 temperature of fluid through instrument (for first fluidnr only) FluidTemp
182 Alarm delay 15 97 7 c 0 255 Yes Yes No No No 3 time alarm and reset action will be delayed when alarm limit has been exceeded AlrmDelay
183 Capacity 0% 3 33 22 f -3.40282E+38 3.40282E+38 Yes Yes No Yes No 0 capacity of instrument at zero 0% in sensor base units (mostly equal to zero) capacity0%
184 Number of channels 12 0 18 c 0 120 Yes No No No No 1 number of instrument channels available for this device NumOfChan
185 Device function 12 0 20 c 0 255 Yes No No No No 5 function of device DeviceFunc
186 Scan channel 4 123 1 c 1 255 Yes Yes No No No 1 Channel number to scan with real time information (to be set once) ScanChan
187 Scan parameter 4 123 3 c 0 255 Yes Yes No No No 8 Parameter number to scan with real time information (to be set once) ScanPar
188 Scan time 4 123 4 i 0 65535 Yes Yes No No No 50 Scan interval time in msec between two samples (to be set once) ScanTime
189 Scan data 22 4 123 10 c -2 Yes No No No No Scanned data with time label (can be readout event by event) ScanData
190 Valve open 8 114 24 f 0 24 Yes Yes No Yes No 0.04 First-step offset current/voltage for valve when opening from 0% ValveOpen
191 Number of runs 20 115 13 c 0 255 Yes Yes No No No 1 Amount of runs of a piston prover (0 = stability check) NrOfRuns
192 Minimum process time 20 115 14 c 0 255 Yes Yes No No No 10 Minimum process time of a piston prover in 0.1 seconds MinProTime
193 Leak rate 20 116 9 f 0 1 Yes Yes No Yes No 0.0001 Leak rate piston prover LeakRate
194 Mode info request 12 115 15 c 4 Yes Yes No Yes No Sets instr. in info mode for 1 read-cycle to check available parameter options ModeInfReq
195 Mode info option list 12 115 16 c 255 Yes No No No No Gives info about possible values of a mode in an array as result of ModeInfo req ModeInfOpt
196 Mode info option description 12 115 17 c 255 Yes No No No No Gives description about one of the mode options ModeInfDes
197 Calibrations options 20 115 18 c 0 255 Yes Yes No Yes No 0 Enables/disables options for calibration device (8 bits for 8 options) CalType
198 Mass flow 20 33 4 f -3.40282E+38 3.40282E+38 Yes No Yes No No 0 Real mass flow in kg/min MassFlow
199 Bus address 23 125 10 c 0 255 Yes Yes No Yes No 2 Fieldbus address (top interface) BusAddress
200 Interface configuration 23 125 3 c 0 3 Yes Yes No No Yes 1 Configuration setting for interface to other bus-systems InterfConf
201 Baudrate 23 125 9 l 0 10000000000 Yes Yes No Yes No 12000000 Fieldbus baudrate (top interface) Baudrate
202 Bus diagnostic string 23 125 20 c -2 Yes No No No No Fieldbus diagnose string (top interface) BusDiagnos
203 Number of vanes 20 115 22 c 0 255 Yes Yes No Yes No 10 Number of vanes for use in a rotor meter NrOfVanes
204 Fieldbus 23 125 21 c -2 Yes No No No No FLOW-BUS Fieldbus name (top interface) Fieldbus
205 fMeasure 2 33 0 f -3.40282E+38 3.40282E+38 Yes No Yes No No 0 measured value for direct reading (in capunits, max.= capacity) fMeasure
