Order and ratio of monitors

13 · CrossDisplay-Switching Config Tool

Arranging channels in the workspace

How to add monitors to the workspace:

1. In the left column, select a channel.

2. Click (left arrow).

In the workspace, each added module is displayed as grey rectangle (2 × 2 units)

with a black frame and is placed at an available position.

3. The rectangle symbolizes the monitor of the computer connected to the channel.

The channel name is shown within the rectangle.

How to remove monitors from the workspace:
1. In the right column, select the rectangle of the monitor you want to remove.

2. Click (left arrow).

Each removed module monitor is added to the list of channels in the left column.

If the monitors are placed as shown on

the left, it is important to mind the exact

horizontal cursor position when reaching

the left or right edge of

Monitor 3

:

In the upper half you can switch to

monitors 1 or 4.

In the lower half you can switch to

monitors 2 or 5.

ADVICE:

You can select multiple channels by pressing

Shift

or

Ctrl

while moving

the mouse.

ADVICE:

You can also drag and drop monitors by mouse or use the rectangle’s

context menu.

ADVICE:

You can select multiple monitors by pressing

Shift

or

Ctrl

while moving

the mouse.

ADVICE:

You can also drag and drop monitors by mouse or use the rectangle’s

context menu.
