44
5 Parts List
Ersatzteileliste Liste de pièces
パーツリスト
En
Parts # Qty Description
Parts List
50474 1 SILICONE TUBE 2x5x300mm
66796 2 SHOCK MOUNT SCREW (CW/ CCW)
67296 2 BIG BORE SHOCK SET (97mm)
67344 1 AIR FILTER BOOT
67345 1 AIR FILTER SET
67347 1 AIR FILTER FOAM SET (INNER/OUTER)
67349 1 MAIN CHASSIS (4mm/HARD ANODIZED)
67350 8 SHOCK BOOTS SET
67351 1 SHOCK END/SHOCK SPRING RETAINER SET
67353 1 6 HOLES SHOCK PISTON SET (6HOLES/1.3,1.4,1.5mm)
67356 1 STONE GUARD SET (RIGHT/LEFT)
67364 1 FUEL TANK STAND-OFF AND FUEL LINE CLIP SET
67366 1 ENGINE BASE / MOUNT SET
67367 1 ENGINE MOUNT SET
67368 1 RADIO TRAY SET
67376 1 SERVO ARM SET
67378 1 SERVO HORN SET
67379 1 PIVOT PLATE (RR/3DEG)
67380 1 PIVOT PLATE (RF/3DEG)
67381 1 REAR SUSPENSION ARM SET
67382 1 REAR CHASSIS STIFFENER MOUNT
67383 1 REAR CHASSIS STIFFENER
67384 1 FRONT HINGE PIN BLOCK (FR)
67385 1 FRONT SUSPENSION ARM SET
67386 1 FRONT HUB CARRIER SET (RIGHT/LEFT/10DEG)
67388 1 FRONT SPINDLE SET (RIGHT/LEFT)
67390 4 KING PIN BUSHING
67391 1 FRONT HINGE PIN BLOCK (FF)
67392 2 STEERING POST
67397 1 STEERING CRANK SET
67398 1 STEERING PLATE
67399 2 STEERING BUSHING
67400 1 STEERING BRACE
67401 1 FRONT CHASSIS STIFFENER
67402 1 AXLE
67404 1 UNIVERSAL JOINT REBUILD KIT
67405 1 DRIVE SHAFT (91mm)
67406 1 CENTER DRIVE SHAFT COUPLING
67407 1 CENTER DRIVE SHAFT (78mm)
67408 1 CENTER DRIVE SHAFT (105mm)
67409 1 REAR SHOCK TOWER
67410 2 SHOCK STAND OFF
67411 1 BODY MOUNT SET
67413 1 FRONT SHOCK TOWER
67415 2 SUSPENSION SHAFT 4x71mm SILVER (FRONT/INNER)
67416 2 SUSPENSION SHAFT 3x43mm SILVER (FRONT/OUTER)
67417 2 SUSPENSION SHAFT 4x68mm BLACK (REAR/INNER)
67418 2 SUSPENSION SHAFT 3x44mm BLACK (REAR/OUTER)
67419 2 DIFFERENTIAL MOUNT
67420 1 CENTER DIFF MOUNT COVER
67421 2 BRAKE DISK ROTOR
67422 1 AIR FILTER BRACE
67423 4 HB DISH WHEELS (YELLOW)
67424 1 FUEL TANK COUPLER AND NUT
67426 1 FUEL FILTER
67428 1 SPUR GEAR 48 TOOTH
67433 2 BIG BORE SHOCK CAP
67435 2 BIG BORE SHOCK BODY (16x97mm)
67436 2 SHOCK SHAFT 4x97mm
67438 2 BALL BEARING 8x14x4mm
67439 2 BALL BEARING 5x11x4mm
67440 1 CLUTCH BELL 16 TOOTH
67444 1 HB D8 BODY (CLEAR)
67446 2 BIG BORE SHOCK SPRING (GRAY/60mm/74gf)
67447 2 BIG BORE SHOCK SPRING (WHITE/60mm/81gf)
67464 2 STEERING TURNBUCKLE 4x55mm
67468 1 EXHAUST HANGER WIRE
67470 6 WASHER 5x8x0.5mm
67472 2 BRAKE CAM
67473 2 BRAKE WIRE
67486 2 WHEEL HEX HUB
67491 2 STEERING LINKAGE SET
67492 4 17MM WHEEL NUT (BLACK)
67493 4 BALL 6mm
67499 1 SPIRAL PINION GEAR 10 TOOTH
67510 1 SWAY BAR (2.8mm)
67511 1 SWAY BAR (2.4mm)
67514 6 SPACER 3x8.5x3mm
67515 1 BIG BORE SHOCK MAINTENANCE SET
67516 1 BALL END SET
67518 1 UNIVERSAL DRIVE SHAFT SET
67520 1 THROTTLE LINKAGE SET
67521 1 WING MOUNT SET
67523 1 FUEL LINE SET
67524 1 FUEL TANK SET
67525 1 FLYWHEEL (3PINS/BLACK)
67528 2 BIG BORE SHOCK SPRING ADJUST NUT (BLACK)
67529 2 BIG BORE SHOCK BOTTOM CAP (BLACK)
67531 1 CNC PIPE MOUNT (BLACK)
86598 10 WASHER 13x16x0.2mm
94388 10 CAP HEAD SCREW M3x16mm
94505 10 CAP HEAD SCREW M4x12mm
94531 10 FLAT HEAD SCREW M4x15mm (HEX SOCKET)
94554 10 BUTTON HEAD SCREW M4x10mm (HEX SOCKET)
94675 8 CAP HEAD SCREW M3.5x14mm
94676 8 CAP HEAD SCREW M3.5x18mm
94677 8 CAP HEAD SCREW M3.5x42mm
100550 10 PAN HEAD SCREW M5x8mm (HEX SOCKET)
100551 4 LOCK NUT M2.5
100553 8 WASHER M2.9x8x0.5mm
100554 4 SET SCREW M3x14mm
100555 4 SET SCREW M4x3mm
100556 10 FLAT HEAD SCREW M3x14mm (HEX SOCKET)
100557 8 FLAT HEAD SCREW M3x16mm (HEX SOCKET)
100558 10 BUTTON HEAD SCREW M3x4mm (HEX SOCKET)
100559 10 BUTTON HEAD SCREW M3x14mm (HEX SOCKET)
100560 10 BUTTON HEAD SCREW M3x16mm (HEX SOCKET)
HB70545 8 BODY CLIP (LIGHTNING SERIES)
HBC8003 1 FRONT BUMPER (LIGHTNING SERIES)
HBC8008 1 REAR WHEEL HUB L, R (LIGHTNING SERIES)
HBC8009-1 1 DIFFERENTIAL CASE (LIGHTNING SERIES)
HBC8017 2 REAR UPPER TURNBUCKLE 5x51mm
HBC8018-1 2 FRONT UPPER TURNBUCKLE 5x30mm (LIGHTNING SERIES)
HBC8019 1 DIFFERENTIAL HOUSING (LIGHTNING SERIES)
HBC8020-1 4 RUBBER SEALED BEARING 8x16mm
HBC8021 3 DIFFERENTIAL PADS (LIGHTNING SERIES)
HBC8022 2 DIFFERENTIAL SHAFT (LIGHTNING SERIES)
HBC8023 6 O-RING 6MM (LIGHTNING SERIES)
HBC8043 3 3PCS RACING CLUTCH SHOE (LIGHTNING SERIES)
HBC8045 3 CLUTCH SPRINGS FOR C8043, C8043-1 (LIGHTNING SERIES)
HBC8048 1 DISK BRAKE PLATE (LIGHTNING SERIES)
HBC8050 4 3X14MM SCREWS (LIGHTNING SERIES)
HBC8051 1 1/8 DECK WING (LIGHTNING SERIES)
HBC8058-1 1 SW. DUST-PROOF COVER BLACK (LIGHTNING SERIES)
HBC8059 1 CENTER GEAR HOUSING (LIGHTNING SERIES)
HBC8064 2 FRONT & REAR DIFF AXLE SHAFT (LIGHTNING SERIES)
HBC8071 2 CENTER DIFF AXLE SHAFT (LIGHTNING SERIES)
HBC8086 1 ANTENNA (LIGHTNING SERIES)
HBC8088 4 6X10MM SEALED BEARING (LIGHTNING SERIES)
HBC8089 4 BALL FOR STEERING PUSH ROD (LIGHTNING SERIES)
HBC8096 4 3X17MM SHAFT (LIGHTNING SERIES)
HBC8098 4 FIXING BALL FOR UPPER SUSPENSION
HBC8099 4 FIXING BALL FOR REAR SUSPENSION
HBC8100 4 6.8MM BALL END (L/LIGHTNING SERIES)
HBC8101-1 1 HARD STEEL DIFFERENTIAL GEAR SET
HBC8108 1 FRONT STABILIZER SET (LIGHTNING SERIES)
HBC8113 10 BODY CLIP (LIGHTNING SERIES)
HBC9010 1 43T SPIRAL BEVEL GEAR (LIGHTNING STADIUM)
Z083 10 FLAT HEAD SCREW M3x10mm (HEX SOCKET)
Z084 10 FLAT HEAD SCREW M3x12mm (HEX SOCKET)
Z086 10 FLAT HEAD SCREW M3x18mm (HEX SOCKET)
Z087 10 FLAT HEAD SCREW M3x20mm (HEX SOCKET)
Z216 4 BUTTON HEAD SCREW M3X15mm (HEX SOCKET)
Z224 10 WASHER M3x8mm
Z307 4 FLAT HEAD SCREW M4x10mm (HEX SOCKET/THIN TYPE)
Z351 10 BUTTON HEAD HEX SOCKET SCREW M3X6MM
Z352 10 BUTTON HEAD SCREW M3x8mm (HEX SOCKET)
Z353 10 BUTTON HEAD SCREW M3x10mm (HEX SOCKET)
Z354 10 BUTTON HEAD SCREW M3x12mm (HEX SOCKET)
Z357 10 BUTTON HEAD SCREW M3x20mm (HEX SOCKET)
Z539 6 CAP HEAD SCREW M3x45mm (BLACK)
Z542 12 CAP HEAD SCREW M3x8mm
Z544 6 CAP HEAD SCREW M3x12mm
Z547 6 CAP HEAD SCREW M3x20mm
Z548 12 CAP HEAD SCREW M3x22mm
Z653 6 NUT M3
Z663 6 LOCK NUT M3
Z664 4 LOCK NUT M4
Z676 4 LOCK NUT M3 THIN TYPE
Z700 6 SET SCREW M3x3mm
Z702 10 SET SCREW M3x5mm
Z704 10 SET SCREW M3x8mm
Z721 4 SET SCREW M4x4mm
Z725 6 SET SCREW M4x10mm
Z740 6 SET SCREW M5x4mm BLACK
Z800 20 SPRING WASHER 3x6mm
Parts # Qty Description
66223 1 DECK WING WHITE
66887 1 HB FACTORY PHILLIPS SCREWDRIVER (6.0x100mm)
66888 1 HB FACTORY PHILLIPS SCREWDRIVER (4.0x100mm)
66889 1 HB FACTORY SLOTTED SCREWDRIVER (4.0x130mm)
66890 1 HB FACTORY SOCKET DRIVER (7.0x80mm)
66891 1 HB FACTORY SOCKET DRIVER (5.5x80mm)
66892 1 HB FACTORY BALL ALLEN WRENCH (2.5x100mm)
66893 1 HB FACTORY BALL ALLEN WRENCH (2.0x100MM)
66894 1 HB FACTORY ALLEN WRENCH (3.0x100mm)
66895 1 HB FACTORY ALLEN WRENCH (2.5x100mm)
66896 1 HB FACTORY ALLEN WRENCH (2.0x100mm)
66897 1 HB FACTORY ALLEN WRENCH (1.5x100mm)
66898 1 HB FACTORY TURNBUCKLE WRENCH (3.7x80mm)
66899 1 HB FACTORY DROOP GAGE
66900 2 HB FACTORY DROOP GAGE BLOCK (20x115mm)
67434 2 BIG BORE SHOCK SPRING ADJUST NUT
67437 2 BIG BORE SHOCK BOTTOM CAP (PURPLE)
67448 2 BIG BORE SHOCK SPRING (BLUE/60mm/89gf)
67449 2 BIG BORE SHOCK SPRING (ORANGE/60mm/98gf)
67450 2 BIG BORE SHOCK SPRING (GREEN/68mm/59gf)
67451 2 BIG BORE SHOCK SPRING (YELLOW/68mm/68gf)
67452 2 BIG BORE SHOCK SPRING (RED/68mm/81gf)
67453 2 BIG BORE SHOCK SPRING (GRAY/76mm/52gf)
67454 2 BIG BORE SHOCK SPRING (WHITE/76mm/59gf)
67455 2 BIG BORE SHOCK SPRING (BLUE/76mm/63gf)
67456 2 BIG BORE SHOCK SPRING (ORANGE/76mm/74gf)
67457 2 BIG BORE SHOCK SPRING (GREEN/96mm/40gf)
67458 2 BIG BORE SHOCK SPRING (YELLOW/96mm/44gf)
67459 2 BIG BORE SHOCK SPRING (RED/96mm/49gf)
67527 4 HB DISH WHEELS (WHITE)
HBC8051-1 1 1/8 DECK WING BLACK (LIGHTNING SERIES)
HBC8122-1 1 SHOCK OIL #250
HBC8122-10 1 SHOCK OIL #550
HBC8122-11 1 SHOCK OIL #600
HBC8122-12 1 SHOCK OIL #1000
HBC8122-13 1 SHOCK OIL #5000
HBC8122-14 1 SHOCK OIL #10000
HBC8122-15 1 SHOCK OIL #650
HBC8122-16 1 SHOCK OIL #700
HBC8122-17 1 SHOCK OIL #2000
HBC8122-2 1 SHOCK OIL #350
HBC8122-3 1 SHOCK OIL #450
HBC8122-4 1 SHOCK OIL #3000
HBC8122-5 1 SHOCK OIL #4000
HBC8122-6 1 SHOCK OIL #7000
HBC8122-7 1 SHOCK OIL #300
HBC8122-8 1 SHOCK OIL #400
HBC8122-9 1 SHOCK OIL #500
Parts # Qty Description Parts # Qty Description
En
Option Parts List
