First steps
4. Using multiple satellites via DiSEqC 1.2
DiSEqC 1.2 provides additional control on the rotary equipment with DiSEqC commands, via a single
coaxial cable. Of the motor's staff was also a record producer (rod USALS) defined which is to find
the satellite position is particularly simple. The appropriate receiver is sufficient to enter the
geographical position and the satellites are found automatically - provided that the curved path of the
rotary engine has been correctly set mechanically.
Motor Antenna
First, you must navigate in this installation menu to the
option Antenna Connection and enter this menu by
the OK button. Then select the “Motor Antenna” by
the
Ż / Ź button. Then exiting to Antenna Connection
menu and entering to Antenna Setup menu.
DiSEqC1.2
Navigate with the arrow key DOWN to the Motor Type
option and select the DiSEqC1.2 with the
Ż / Ź
button. Then navigate with the arrow key DOWN to
the Motor Setting option and press the OK button.
Motor Setting
The menu is now expanded to the “DiSEqC 1.2”
settings.
x
Satellite
x
Transponder
x
Position NO. & Save
x
Go to x
x ŻSaveŹ
x
Recalculation
Satellite/ Transponder
Select a Satellite and a Transponder .
Position No. & Save
Press the
Ż / Ź button and select one of the 64
settings (0 to 63). You also can press the numeric
keys directly to input the Position No..
Go to x
Press the OK button and select one of the 64 settings
(0 to 63). Confirm your selection with the OK button
and it appears a message on the screen "Wait to
move the position!”
ŻSaveŹ
You can press
Ż / Ź button to move the dish. When it moves to the correct position, you can press
the OK button to save this position.
Recalculation
You can press OK button to recalculate.
Channel Search
