12
10±0.3
// 0.1 F
79±0.3
62±0.3
0.1
// 0.1 F
15±0.3
25±0.2
// 0.3
0.05
F
// 0.1
45±0.3
// 0.1
k
k
k
k
k
k
Montage-Möglichkeiten und Anbautoleranzen
F =
Maschinenführung
=
Kundenseitige
Anschlussmaße
Mounting possibilities and tolerances
F =
Machine
guideway
= Required mating dimensions
Waagerechter Anbau ist möglich.
A horizontal mounting attitude is possible.
Montage-Toleranzen
Mounting Tolerances
