MA000 (de_en)
Montageanleitung
MA000 (de_en)
Assembly instructions
MA082 (de_en)
Montageanleitung
MA082 (de_en)
Assembly instructions
Steckverbinder
MPC-S
Connectors
MPC-S
Inhalt
Lieferstatus der Komponenten ��������������������������������������������������1
Sicherheitshinweise....................................................................2
Empfohlenes Werkzeug ������������������������������������������������������������3
Vorbereitung der Leitung �����������������������������������������������������������6
Kontakt Crimpung ���������������������������������������������������������������������6
Vorbereitung des Steckverbinderkörpers ����������������������������������7
Kennzeichnung ��������������������������������������������������������������������������9
Zusammenbau der Kontakte im Steckverbinder �����������������������9
Festziehen der Kabelverschraubung ����������������������������������������12
Verwendung des Steckverbinders �������������������������������������������12
Anschluss und Trennung des Steckverbinders �����������������������13
Zubehör �����������������������������������������������������������������������������������13
Anwendungsbeispiele �������������������������������������������������������������14
Notizen �������������������������������������������������������������������������������15-16
Content
Components delivery �����������������������������������������������������������������1
Safety Instructions ......................................................................2
Suggested tools �������������������������������������������������������������������������3
Cable preparation ����������������������������������������������������������������������6
Contact crimping �����������������������������������������������������������������������6
Preparation of the connector‘s body �����������������������������������������7
Marking �������������������������������������������������������������������������������������9
Assembling the contacts into the body of the connector ���������9
Tightening of the cable gland ��������������������������������������������������12
Using the connector ����������������������������������������������������������������12
Connecting and disconnecting the connector ������������������������13
Accessories �����������������������������������������������������������������������������13
Application examples ��������������������������������������������������������������14
Notes ����������������������������������������������������������������������������������15-16
Lieferstatus der Komponenten
Status of components delivery
1. Kupplungskörper für Stecker oder Buchse
2. Crimpkontakte
3. Haltering der Kontakte in der Isolation
4. Kodierstiften
5. Kennzeichnungsstiften
6. Kabelverschraubung-Einsätze
1. Body configuration male or female
2. Contacts to be crimped
3. Retaining rings
4. Coding pins
5. Marking pins
6. Cable gland inserts
