Advanced Contact Technology

www.multi-contact.com

1 / 20

PV-JB-LC...

MA000 (de_en)
Montageanleitung

MA000 (de_en)
Assembly instructions

MA246 (de_en)
Montageanleitung

MA246 (de_en)
Assembly instructions

PV-Paneldose
PV-JB-LC...

PV-Junction box
PV-JB-LC

Inhalt
Sicherheitshinweise................................................................ 2-3
Erforderliches Werkzeug �����������������������������������������������������������4
Erforderliche Hilfsmittel �������������������������������������������������������������4
Vorbereiten der Modulrückseiten ����������������������������������������������5
Reinigung der Oberflächen��������������������������������������������������������5
Allgemeine Hinweise �����������������������������������������������������������������5
Reinigung der Modulrückseiten ������������������������������������������������5
Vorbehandlung der Modulrückseiten ����������������������������������������5
Anwendung der empfohlenen Primer ���������������������������������������5
Aufbringen der Paneldose (Klebefolien-Applikation) �����������������7
Einrichten des Hilfswerkzeugs ��������������������������������������������������7
Vorbereiten der Flachbandleiter ������������������������������������������������8
Einsetzen der Paneldose in das
Hilfswerkzeug PV-WZ-JB/LC �����������������������������������������������������8
Montage der Flachbandleiter ����������������������������������������������������9
Montage der Paneldose auf das PV-Modul �������������������������������9
Wichtiger Hinweis zur Klebeverbindung ���������������������������������11
Hinweise zur Montage der Paneldose
auf das PV-Modul ohne Zuhilfenahme
des MC Hilfswerkzeugs PV-WZ-JB/LC ������������������������������������11
Aufbringen der Paneldose (Silikon-Applikation) ����������������������12
Leitungsführung ����������������������������������������������������������������������16
Technische Daten ��������������������������������������������������������������������17

Content
Safety Instructions .................................................................. 2-3
Tools required ����������������������������������������������������������������������������4
Auxiliary materials required �������������������������������������������������������4
Preparing the backs of the modules ������������������������������������������5
Cleaning the surfaces ����������������������������������������������������������������5
General notes ����������������������������������������������������������������������������5
Cleaning the backs of the modules �������������������������������������������5
Pre-treatment of the module backs �������������������������������������������5
Using the recommended primer �����������������������������������������������5
Fixing the junction box in place (Adhesive foil application) ������7
Setting up the auxiliary tool �������������������������������������������������������7
Preparing the ribbon conductors �����������������������������������������������8
Inserting the junction box in the auxiliary tool
PV-WZ-JB/LC �����������������������������������������������������������������������������8
Fitting the ribbon conductors ����������������������������������������������������9
Mounting the junction box on the PV module ��������������������������9
Important note on the adhesive bond �������������������������������������11
Notes on the fixing of the junction box
on the PV module without the use of
the MC auxiliary PV-WZ-JB/LC �����������������������������������������������11
Fixing the junction box (Silicone Application) �������������������������12
Cable routing ��������������������������������������������������������������������������16
Technical data ��������������������������������������������������������������������������17

Engineering considerations according to UL File E335016
File E335016, Vol 1, Sec� 1
ENGINEERING CONSIDERATIONS:
Use - For use only with complete equipment where the acceptability of the combination is determined by Underwriters Labora-
tories Inc�
Conditions of Acceptability - In order to be judged acceptable as a component of electrical equipment, the following condi-
tions should be met:

1� These devices are intended for use with single-conductor cable and have been evaluated for strain relief of (ZKLA PV-Wire / TYLZ USE-2

Cable) Photovoltaic Cable, 12 AWG, and metric size cable of 4 mm², 7�05 mm cable outside diameter�

2� The suitability of the mounting means of attachment to the backsheet of the end-product module shall be determined in the end use�

3� The UL 1703 Temperature test, Strain Relief test, Water Spray, Wet Insulation Resistance and Humidity cycling test sequences, shall be

conducted in the end use equipment�

4� These components have not been assessed for a maximum series fuse amp rating� The maximum series fuse amp rating should be as-

sessed in the end product�

5� These devices should be used only where they will not interrupt current. In addition, the need to include specific instructions in the end use

equipment’s manual describing the method of achieving disconnect while not under load should be observed�
