Installation
4 · G&D UserCenter CAT8
Establishing the power supply
Plug the power cable (PowerCable-2 Standard) in the Main Power socket.
Optional: Plug the power pack which is available as accessories in the Red. Power
socket. This establishes a second, redundant power supply of the device.
Initiation
Switch on the device at the button above the Main Power socket.
Figure 3: Exemplary connection of a CPU and the respective clusters ports
Red. Power
12V DC
3.1
3.2
3.3
3.4
3.5
3.6
3.7
3.8
CPU 3
Cluster
1.1
1.2
1.3
1.4
1.5
1.6
1.7
1.8
CPU 1
Cluster
CATCenter 4
CATCenter 3
CATCenter 2
CATCenter 1
CATCenter 5
CATCenter 6
CATCenter 7
CATCenter 8
target module
