Status displays
6 · G&D UserCenter CAT8
2 Active flashing A user of one of the connected matrix switches is
accessing the target module.
off The target module is currently not being accessed.
Status flashing The connection between the target module and the
matrix switch has been successfully established.
blinking The connection between the target module and the
G&D matrix switch could not be established.
Check if the target module and the G&D matrix
switch are properly connected.
3 Active flashing A user of one of the connected matrix switches is
accessing the target module.
off The target module is currently not being accessed.
Status flashing The connection between the target module and the
matrix switch has been successfully established.
blinking The connection between the target module and the
G&D matrix switch could not be established.
Check if the target module and the G&D matrix
switch are properly connected.
4 Active flashing A user of one of the connected matrix switches is
accessing the target module.
off The target module is currently not being accessed.
Status flashing The connection between the target module and the
matrix switch has been successfully established.
blinking The connection between the target module and the
G&D matrix switch could not be established.
Check if the target module and the G&D matrix
switch are properly connected.
Sector LED Status Meaning
Table 2: Meaning of the different LEDs (continued)
