Meinberg VME31 - Handbuch (Seite 15)

15
Steckerbelegung
a b c
1 D0
2 D1
3 D2
4 D3 /BG0IN
5 D4 /BG0OUT
6 D5 /BG1IN
7 D6 /BG1OUT
8 D7 /BG2IN
9 GND /BG2OUT GND
10 SYSCLK /BG3IN /SYSFAIL
11 GND /BG3OUT /BERR
12 /SYSRESET
13 /DS0 /LWORD
14 /WRITE AM5
15 GND
16 /DTACK AM0
17 GND AM1
18 /AS AM2
19 GND AM3
20 /IACK GND
21 /IACKIN
22 /IACKOUT
23 AM4 GND A15
24 /IRQ7 A14
25 /IRQ6 A13
26 /IRQ5 A12
27 A4 /IRQ4 A11
28 A3 /IRQ3 A10
29 A2 /IRQ2
30 A1 /IRQ1
31
32 VCC in (+5V) VCC in (+5V) VCC in (+5V)
