5
7.2 Exposure
• BRIGHTNESS: Adjust brightness level
0 (dark) ~ 0 (bright) steps
• LENS: MANUAL
• SHUT SPEED: Can be set in AUTO or MANUAL
AUTO / /30 (5), /60 (50), /0 (00), /40, /500, /000, /000, /4000, /8000, /6000, /30000,
/60000 sec
• DSS: Select maximum DSS (Digital Slow Shutter)
OFF / x, x3, x4
• AGC: Select Auto Gain Control
OFF/ON
• WDR/ BLC: Select WDR (Wide Dynamic Range) or BLC (Back Light Compensation)
WDR
WEIGHT: Adjust WDR level - 0 ~ 3
BLC
AREA: Control BLC area according to light condition
POS-X: Adjust the window X-Axis position
POS-Y: Adjust the window Y-Axis position
SIZ-X: Adjust the window X-Axis size
SIZ-Y: Adjust the window Y-Axis size
NOTE: When WDR is ON, ACE and DEFOG functions do not turn on.
• DAY& NIGHT: Select Day& Night
AUTO / DAY / NIGHT / EXT
Delay: 0 ~ 55 sec
BURST: OFF / ON
THRS: LOW / MIDDLE / HIGH
Select Day&Night change level. Higher level make the night mode changed in lower illumination.
GAP: LOW / MIDDLE / HIGH
Select the switchover delay time from Day to Night, and from Night to Day.
