Eneo HDD-2110M1080 - Handbuch (Seite 28)

8
7.5 Intelligence
• PRIVACY: Hide an on screen screen area
OFF / ON
MASK#: Select mask area number (0 ~ 3)
MODE: Set-up masking areas (OFF / ON)
X-POS: Adjust the mask X-Axis position
Y-POS: Adjust the mask Y-Axis position
X-SIZ: Adjust the mask X-Axis size
Y-SIZ: Adjust the mask Y-Axis size
COLOR: Cyan, Green, Magenta, Red, Blue, Black, White, Yellow
TRANS: Select mask transparency level (0 ~ 4)
• MOTION: If there is subject movement on the screen, this is detected as motion by the camera.
OFF / ON
SENSITIVITY: Adjust sensitivity of MD (0 ~ 0 steps)
More sensitive to lower settings for sensitivity
AREA: Designate motion detection area (WHOLE / EACH)
– AREA#: Setting 3 areas (0~) for motion detection
– MODE: Limit and define areas of motion detection
– X-POS: Adjust the mask X-Axis position
– Y-POS: Adjust the mask Y-Axis position
– X-SIZ: Adjust the mask X-Axis size
– Y-SIZ: Adjust the mask Y-Axis size
– TRANS: Adjust colour tone of out of selected areas
INTERVAL: Select the alarm interval time (0 ~ 55 sec)
DWELL: Select the duration time for changing MD mode (0 ~ 55 sec)
RETURN
