8
Assembly
FGW 84 A1
GB
IE
Step 7
Secure the wooden grip onto the rear part of the skewer (straight edge) ♦
with light hammer blows. Slide the barbecue racks onto the skewer.
Secure the barbeque racks with the eye screws M4 x 10.
Assemble the two handles onto the grill grate ♦ 5 .
Step 8
Place the grill grate ♦ 5 and the skewer garniture into the wind
protector 2 3 4 .
To fi nish the assembly, tighten all screw connections fi rmly. ♦
5
5
2
3 4
